A·X·U·M User Manual Version 2.5 - 2011-01-28
AXUM from D&R - Phone: +31 294 418014 - E-Mail: info@d-r.nl - 36 -
6.1.11.4 Routing
The field ‘Use at source select’ determines if the default module routing is used when a source is
assigned via the module source select functionality .
The following routing sections are available:
• Buss level
You may predefine the send level of a module to the busses (e.g. Aux send).
• Buss status
You have to setup the startup status for the busses. With this setting you set the buss routing
(e.g. Program on/off or CUE on/off).
• Buss Pre/Post
It’s possible to have pre/post selection per module, the startup setting can be configured here.
• Balance
You can select the balance of the buss sent.
6.1.11.5 Set module 1 to programmed startup state
When you click this button the module will directly load the setup module defaults.
