1 Load share/regeneration terminals (optional) 6 Slotted drive bracket
2 Bottom panel 7 Plastic gland plate (installed)
3 Terminal cover 8 Fastener point
4 Grommet access hole for control wiring 9 Keyhole opening
5 Track guide – –
Illustration 4.8 Assembling the Gland Plate and Terminal Cover
Mechanical Installation Operating Guide
MG16O102 Danfoss A/S © 01/2017 All rights reserved. 19
4 4
