Danfoss FC 300

FC 300 Operating Instructions
How to Programme
" 7-** Controllers
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
7-0* S peed PID Ctrl.
7-00 Speed PID Feedback Source - All set-ups FALSE - Uint8
7-02 Speed PID Proportional Gain SR All set-ups TRUE -3 Uint16
7-03 Speed PID Integral Time SR All set-ups TRUE -4 Uint32
7-04 Speed PID Differentiation Time SR All set-ups TRUE -4 Uint16
7-05 Speed PID Diff. Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
7-06 Speed PID Lowpass Filter T ime 10.0 ms All set-ups TRUE -4 Uint16
7-08 Speed PID Feed Forward Factor 0 % All set-ups FALSE 0 Uint16
7-2* Proce s s Ctrl. Feedb
7-20 Process CL Feedback 1 Resource [0] No function All set-ups TRUE - Uint8
7-22 Process CL Feedback 2 Resource [0] No function All set-ups TRUE - Uint8
7-3* Process PID Ctrl.
7-30 Process PID Normal/ Inverse
Control [0] Norm al All set-ups TRUE - Uint8
7-31 Process PID Anti Windup [1] On All set-ups TRUE - Uint8
7-32 Process PID Start Speed 0 RPM All set-ups TRUE 67 Uint16
7-33 Process PID Proportional Gain 0.01 All set-ups TRUE -2 Uint16
7-34 Process PID Integral Time 10000.00 s All set-ups TRUE -2 Uint32
7-35 Process PID Differentiation Time 0.00 s All set-ups TRUE -2 Uint16
7-36 Proc ess PID Diff. Gain Limit 5.0 All set-ups TRUE -1 Uint16
7-38 Process PID Feed Forward Factor 0 % All set-ups TR U E 0 Uint16
7-39 On Reference Bandwidth 5 % All set-ups TRUE 0 Uint8
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
51
MG.33.A7.02 - VLT is a registered Danfoss trademark
