FC 300 Operating Instructions
How to Programme
" 9-** Profibus
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
9-00 Setpoint 0 All set-ups TR U E 0 Ui nt16
9-07 Actual Value 0 All set-ups FALSE 0 Uint16
9-15 PCD Write Configuration SR 2 set-ups TRUE - Uint16
9-16 PCD Read Configuration SR 2 set-ups TRUE - Uint16
9-18 Node Address 126 1 set-up TRUE 0 Uint8
9-22 Telegram Selection [108] PPO 8 1 set-up TRUE - Uint8
9-23 Parameters for Signals 0 All set-ups TRUE - Uint16
9-27 Parameter Edit [1] Enabled 2 set-ups FALSE - Uint16
9-28 Process Control
[1] Enable cyclic
master 2 set-ups FALSE - Uint8
9-44 Fault Message Counter 0 All set-ups TRUE 0 Uint16
9-45 Fault Co d e 0 All set-ups TRUE 0 U i nt 16
9-47 Fault Number 0 All set-ups TRUE 0 Uint16
9-52 Fau lt Situation Counter 0 All set-ups TRUE 0 Uint16
9-53 Profibus Warning Word 0 All set-ups TRUE 0 V2
9-63 Actual Baud Rate
[255] No baudrate
found All set-ups TRUE - Uint8
9-64 Device Identification 0 All set-ups TRUE 0 Uint16
9-65 Profile Number 0 All set-ups TRUE 0
Oct-
Str[2]
9-67 Control Word 1 0 All set-ups TRUE 0 V2
9-68 Status Word 1 0 All set-ups TRUE 0 V2
9-71 Profibus Save Data Values [0] Off All set-ups TRUE - Uint8
9-72 ProfibusDriveReset [0] No action 1 set-up FALSE - Uint8
9-80 Defined Parameters (1) 0 All set-ups FALSE 0 Uint16
9-81 Defined Parameters (2) 0 All set-ups FALSE 0 Uint16
9-82 Defined Parameters (3) 0 All set-ups FALSE 0 Uint16
9-83 Defined Parameters (4) 0 All set-ups FALSE 0 Uint16
9-84 Defined Parameters (5) 0 All set-ups FALSE 0 Uint16
9-90 Changed Parameters (1) 0 All set-ups FALSE 0 Uint16
9-91 Changed Parameters (2) 0 All set-ups FALSE 0 Uint16
9-92 Changed Parameters (3) 0 All set-ups FALSE 0 Uint16
9-93 Changed parameters (4) 0 All set-ups FALSE 0 Uint16
9-94 Changed parameters (5) 0 All set-ups FALSE 0 Uint16
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
53
MG.33.A7.02 - VLT is a registered Danfoss trademark
