Enabling diagnosis may cause increased bus traffic. Diagnosis
functions are not supported by all fieldbus types.
2.11.3. 8-1* Ctrl. Word Settings
Parameters for configuring the option control word profile.
8-10 Control Word Profile
Option: Function:
[0]
*
FC profile
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402 Select the interpretation of the control and status words corre-
sponding to the installed fieldbus. Only the selections valid for
the fieldbus installed in slot A will be visible in the LCP display.
For guidelines in selection of
FC profile [0] and PROFIdrive pro-
file
[1] please refer to the Serial communication via RS 485
Interface
section.
For additional guidelines in the selection of
PROFIdrive profile
[1], ODVA [5] and CANopen DSP 402 [7], please refer to the
Operating Instructions for the installed fieldbus.
8-13 Configurable Status Word STW
Option: Function:
This parameter enables configuration of bit 12 – 15 in the status
word.
[0] No function
[1]
*
Profile default Function corresponds to the profile default selected in par. 8-10.
[2] Alarm 68 only Only set in case of an Alarm 68.
[3] Trip except Alarm 68 Set in case of a trip, except if the trip is executed by an Alarm
68.
[16] T37 DI status The bit indicates the status of terminal 37.
“0” indicates T37 is low (safe stop)
“1” indicates T37 is high (normal)
2.11.4. 8-3* FC Port Settings
Parameters for configuring the FC Port.
8-30 Protocol
Option: Function:
[0]
*
FC
[1] FC MC Select the protocol for the FC (standard) port.
