Danfoss FC 300

Bit: Meaning:
0 Connection with DP-master is not
1Not used
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 Baudrate search
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 Drive is tripped
9 Internal CAN error
10 Wrong configuration data from PLC
11 Wrong ID sent by PLC
12 Internal error occured
13 Not configured
14 Timeout active
15 Warning 34 active
9-63 Actual Baud Rate
Option: Function:
This parameter displays the actual Profibus baud rate. The Pro-
fibus Master automatically sets the baud rate.
Read only
[0] 9.6 kbit/s
[1] 19.2 kbit/s
[2] 93.75 kbit/s
[3] 187.5 kbit/s
[4] 500 kbit/s
[6] 1500 kbit/s
[7] 3000 kbit/s
[8] 6000 kbit/s
[9] 12000 kbit/s
[10] 31.25 kbit/s
[11] 45.45 kbit/s
[255] No baud rate found
9-64 Device Identification
Range: Function:
0
*
[0 - 0] This parameter displays the device identification. Please refer to
the
Operating Instructions for Profibus, MG33CXYY for further
explanation.
9-65 Profile Number
Range: Function:
Read only
0
*
[0 - 0] This parameter contains the profile identification. Byte 1 con-
tains the profile number and byte 2 the version number of the
profile.
NB!
This parameter is not visible via LCP.
