[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5 Select the boolean (TRUE or FALSE) input to activate Smart
Logic Control.
False
[0] enters the fixed value - FALSE.
True
[1] enters the fixed value - TRUE.
Running
[2] The motor is running.
In range
[3] The motor is running within the programmed cur-
rent and speed ranges set in par. 4-50 to par. 4-53.
On reference
[4] The motor is running on reference.
Torque limit
[5] The torque limit, set in par. 4-16 or 4-17, has
been exceeded.
Current limit
[6] The motor current limit, set in par. 4-18, has
been exceeded.
Out of current range
[7] The motor current is outside the range
set in par. 4-18.
Below I low
[8] The motor current is lower than set in par. 4-50.
Above I high
[9] The motor current is higher than set in par.
4-51.
Out of speed range
[10] The speed is outside the range set in
par. 4-52 and 4-53.
Below speed low
[11] The output speed is lower than the setting
in par. 4-52.
Above speed high
[12] The output speed is higher than the set-
ting in par. 4-53.
Out of feedb. Range
[13] The feedback is outside the range set
in par. 4-56 and 4-57.
Below feedb. Low
[14] The feedback is below the limit set in
par. 4-56.
Above feedb. High
[15] The feedback is above the limit set in
par. 4-57.
Thermal warning
[16] The thermal warning turns on when the
temperature exceeds the limit in the motor, the frequency con-
verter, the brake resistor or the thermistor.
Mains out of range
[17] The mains voltage is outside the speci-
fied voltage range.
Reversing
[18] The output is high when the drive is running
counter clockwise (the logical product of the status bits “run-
ning” AND “reverse”).
Warning
[19] A warning is active.
Alarm (trip)
[20] A (trip) alarm is active.
Alarm (trip lock)
[21] A (Trip lock) alarm is active.
Comparator 0
[22] Use the result of comparator 0.
Comparator 1
[23] Use the result of comparator 1.
Comparator 2
[24] Use the result of comparator 2.
Comparator 3
[25] Use the result of comparator 3.
Logic rule 0
[26] Use the result of logic rule 0.
Logic rule 1
[27] Use the result of logic rule 1.
Logic rule 2
[28] Use the result of logic rule 2.
FC 300 Programming Guide 2. How to Programme
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark
155
2
