Logic rule 3 [29] Use the result of logic rule 3.
Digital input DI18 [33] Use the result of digital input 18.
Digital input DI19 [34] Use the result of digital input 19.
Digital input DI27 [35] Use the result of digital input 27.
Digital input DI29 FC302Only [36] Use the result of digital input
29.
Digital input DI32 [37] Use the result of digital input 32.
Digital input DI33 [38] Use the result of digital input 33.
Start command [39] A start command is issued.
Drive stopped [40] A stop command ( Jog, Stop, Qstop, Coast)
is issued – and not from the SLC itself.
Reset Trip [41] A reset is issued
Auto-reset Trip [42] An Auto reset is performed.
OK key [43] The Ok key is pressed.
Reset key [44] The reset key is pressed.
Left key [45] The left key is pressed.
Right key [46] The right key is pressed.
Up key [47] The up key is pressed.
Down key [48] The down key is pressed.
Comparator 4 [50] Use the result of comparator 4.
Comparator 5 [51] Use the result of comparator 5.
Logic rule 4 [60] Use the result of logic rule 4.
Logic rule 5 [61] Use the result of logic rule 5.
13-02 Stop Event
Option: Function:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
