Danfoss FC 300

[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29 (FC
302 only)
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7 Select the boolean (TRUE or FALSE) input to activate Smart
Logic Control.
For descriptions [0] - [61], see 13-01
Start Event
SL Time-out 3
[70] Smart logic controller timer 3 is timed out.
SL Time-out 4 [71] Smart logic controller timer 4 is timed out.
SL Time-out 5 [72] Smart logic controller timer 5 is timed out.
SL- Time-out 6 [73] Smart logic controller timer 6 is timed out.
SL Time-out 7 [74] Smart logic controller timer 7 is timed out.
