Danfoss FC 300

13-03 Reset SLC
Option: Function:
[0]
*
Do not reset SLC Retains programmed settings in all group 13 parameters (13-*).
[1] Reset SLC Resets all group 13 parameters (13-*) to default settings.
2.14.3. 13-1* Comparators
Comparators are used for comparing continuous variables (i.e. output frequency, output current,
analog input etc.) to fixed preset values. In addition, there are digital values that will be compared
to fixed time values. See explanation in par. 13-10. Comparators are evaluated once in each scan
interval. Use the result (TRUE or FALSE) directly. All parameters in this parameter group are array
parameters with index 0 to 5. Select index 0 to programme Comparator 0, select index 1 to pro-
gramme Comparator 1, and so on.
13-10 Comparator Operand
Array [6]
Choice [1] to [31] are variables which will be compared based on their values. Choice [50] to [186]
are digital values (TRUE/FALSE) where the comparison is based on the amount of time during
which they are set to TRUE or FALSE, respectively. See par. 13-11.
Select the variable to be monitored by the comparator.
[0] *
DISABLED DISABLED [0] The comparator is disabled.
[1] Reference
Reference [1] The resulting remote reference (not local) as a
percentage.
[2] Feedback
Feedback [2] In the unit [RPM] or [Hz]
[3] Motor speed
Motor speed [3] [RPM] or [Hz]
[4] Motor current
Motor current [4] [A]
[5] Motor torque
Motor torque [5] [Nm]
[6] Motor power
Motor power [6] [kW] or [hp]
[7] Motor voltage
Motor voltage [7] [V]
[8] DC-link voltage
DC-link voltage [8] [V]
[9] Motor thermal
Motor thermal [9] Expressed as a percentage.
[10] VLT thermal
VLT thermal [10] Expressed as a percentage.
[11] Heat sink temp.
Heat sink temp [11] Expressed as a percentage.
[12] Analog input AI53
Analog input AI53 [12] Expressed as a percentage.
[13] Analog input AI54
Analog input AI54 [13] Expressed as a percentage.
[14] Analog input AIFB10
Analog input AIFB10 [14] [V]
[15] Analog input AIS24V
Analog input AIS24V [15] [V] Analog input AICCT [17] [°].
[17] Analog input AICCT
