[4] Select set-up 3 Select set-up 3 [4] - changes the active set-up (par. 0-10) to ‘3’.
[5] Select set-up 4
Select set-up 4 [5] - changes the active set-up (par. 0-10) to ‘4’.
If the set-up is changed, it will merge with other set-up com-
mands coming from either the digital inputs or via a fieldbus.
[10] Select preset refer-
ence 0
Select preset reference 0 [10] – selects preset reference 0.
[11] Select preset refer-
ence 1
Select preset reference 1 [11] – selects preset reference 1.
[12] Select preset refer-
ence 2
Select preset reference 2 [12] – selects preset reference 2.
[13] Select preset refer-
ence 3
Select preset reference 3 [13] – selects preset reference 3.
[14] Select preset refer-
ence 4
Select preset reference 4 [14] – selects preset reference 4.
[15] Select preset refer-
ence 5
Select preset reference 5 [15] – selects preset reference 5.
[16] Select preset refer-
ence 6
Select preset reference 6 [16] – selects preset reference 6.
[17] Select preset refer-
ence 7
Select preset reference 7 [17] - selects preset reference 7. If
the active preset reference is changed, it will merge with other
preset reference commands coming from either the digital in-
puts or via a fieldbus.
[18] Select ramp 1
Select ramp 1 [18] - selects ramp 1.
[19] Select ramp 2
Select ramp 2 [19] - selects ramp 2.
[20] Select ramp 3
Select ramp 3 [20] - selects ramp 3.
[21] Select ramp 4
Select ramp 4 [21] - selects ramp 4.
[22] Run
Run [22] - issues a start command to the frequency converter.
[23] Run reverse
Run reverse [23] - issues a start reverse command to the fre-
quency converter.
[24] Stop
Stop [24] - issues a stop command to the frequency converter.
[25] Qstop
Qstop [25] - issues a quick stop command to the frequency
converter.
[26] Dcstop
Dcstop [26] - issues a DC stop command to the frequency con-
verter.
[27] Coast
Coast [27] - the frequency converter coasts immediately. All
stop commands including the coast command stop the SLC.
[28] Freeze output
Freeze output [28] - freezes the output frequency of the fre-
quency converter.
[29] Start timer 0
Start timer 0 [29] - starts timer 0, see par. 13-20 for further
description.
[30] Start timer 1
Start timer 1 [30] - starts timer 1, see par. 13-20 for further
description.
[31] Start timer 2
Start timer 2 [31] - starts timer 2, see par. 13-20 for further
description.
