Danfoss FC 300

[29] Logic rule 3
[30] SL Time-out 0
[31]
[32]
SL Time-out 1
SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29 (FC
302 only)
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7 Select the boolean input (TRUE or FALSE) to define the Smart
Logic Controller event.See par. 13-01
Start Event ([0] - [61])
and par. 13-02
Stop Event ([70] - [74]) for further description.
13-52 SL Controller Action
Array [20]
[0] *
Disabled Select the action corresponding to the SLC event. Actions are
executed when the corresponding event (defined in par. 13-51)
is evaluated as true. The following actions are available for se-
lection:
*DISABLED [0]
[1] No action
No action [1]
[2] Select set-up 1
Select set-up 1 [2] - changes the active set-up (par. 0-10) to ‘1’.
[3] Select set-up 2
Select set-up 2 [3] - changes the active set-up (par. 0-10) to ‘2’.
FC 300 Programming Guide 2. How to Programme
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark 169
2
