Danfoss FC 300

Par. No. # Parameter description Default value 4-set-up FC 302
only
Change during op-
eration
Conver-
sion index
Type
5-6* Pulse Output 5-60 Terminal 27 Pulse Output Variable null All set-ups TRUE - Uint8 5-62 Pulse Output Max Freq #27 ExpressionLimit All set-ups TRUE 0 Uint32
5-63 Terminal 29 Pulse Output Variable null All set-ups x TRUE - Uint8
5-65 Pulse Output Max Freq #29 ExpressionLimit All set-ups x TRUE 0 Uint32
5-66 Terminal X30/6 Pulse Output Variable null All set-ups TRUE - Uint8
5-68 Pulse Output Max Freq #X30/6 ExpressionLimit All set-ups TRUE 0 Uint32 5-7* 24V Encoder Input 5-70 Term 32/33 Pulses per Revolution 1024 N/A All set-ups FALSE 0 Uint16 5-71 Term 32/33 Encoder Direction [0] Clockwise All set-ups FALSE - Uint8 5-9* Bus Controlled 5-90 Digital & Relay Bus Control 0 N/A All set-ups TRUE 0 Uint32 5-93 Pulse Out #27 Bus Control 0.00 % All set-ups TRUE -2 N2
5-94 Pulse Out #27 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
5-95 Pulse Out #29 Bus Control 0.00 % All set-ups x TRUE -2 N2
5-96 Pulse Out #29 Timeout Preset 0.00 % 1 set-up x TRUE -2 Uint16
