Danfoss FC 300

Par. No. # Parameter description Default value 4-set-up FC 302
only
Change during op-
eration
Conver-
sion index
Type
6-0* Analog I/O Mode 6-00 Live Zero Timeout Time 10 s All set-ups TRUE 0 Uint8 6-01 Live Zero Timeout Function [0] Off All set-ups TRUE - Uint8 6-1* Analog Input 1 6-10 Terminal 53 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-11 Terminal 53 High Voltage 10.00 V All set-ups TRUE -2 Int16 6-12 Terminal 53 Low Current 0.14 mA All set-ups TRUE -5 Int16
6-13 Terminal 53 High Current 20.00 mA All set-ups TRUE -5 Int16
6-14 Terminal 53 Low Ref./Feedb. Value 0 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
6-15 Terminal 53 High Ref./Feedb. Value ExpressionLimit All set-ups TRUE -3 Int32
6-16 Terminal 53 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16 6-2* Analog Input 2 6-20 Terminal 54 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-21 Terminal 54 High Voltage 10.00 V All set-ups TRUE -2 Int16 6-22 Terminal 54 Low Current 0.14 mA All set-ups TRUE -5 Int16
6-23 Terminal 54 High Current 20.00 mA All set-ups TRUE -5 Int16
6-24 Terminal 54 Low Ref./Feedb. Value 0 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
6-25 Terminal 54 High Ref./Feedb. Value ExpressionLimit All set-ups TRUE -3 Int32
6-26 Terminal 54 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16 6-3* Analog Input 3 6-30 Terminal X30/11 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-31 Terminal X30/11 High Voltage 10.00 V All set-ups TRUE -2 Int16 6-34 Term. X30/11 Low Ref./Feedb. Value 0 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
6-35 Term. X30/11 High Ref./Feedb. Value ExpressionLimit All set-ups TRUE -3 Int32
6-36 Term. X30/11 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16 6-4* Analog Input 4 6-40 Terminal X30/12 Low Voltage 0.07 V All set-ups TRUE -2 Int16 6-41 Terminal X30/12 High Voltage 10.00 V All set-ups TRUE -2 Int16 6-44 Term. X30/12 Low Ref./Feedb. Value 0 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
6-45 Term. X30/12 High Ref./Feedb. Value ExpressionLimit All set-ups TRUE -3 Int32
6-46 Term. X30/12 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16 6-5* Analog Output 1 6-50 Terminal 42 Output null All set-ups TRUE - Uint8 6-51 Terminal 42 Output Min Scale 0.00 % All set-ups TRUE -2 Int16 6-52 Terminal 42 Output Max Scale 100.00 % All set-ups TRUE -2 Int16
6-53 Terminal 42 Output Bus Control 0.00 % All set-ups TRUE -2 N2
6-54 Terminal 42 Output Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16 6-6* Analog Output 2 6-60 Terminal X30/8 Output null All set-ups TRUE - Uint8 6-61 Terminal X30/8 Min. Scale 0.00 % All set-ups TRUE -2 Int16 6-62 Terminal X30/8 Max. Scale 100.00 % All set-ups TRUE -2 Int16
2.19.7. 6-** Analog In/Out
2. How to Programme FC 300 Programming Guide
