Danfoss FC 300

[22] Analog input X30-12
3-16 Reference Source 2
Option: Function:
Select the reference input to be used for the second reference
signal. Par. 3-15, 3-16 and 3-17 define up to three different ref-
erence signals. The sum of these reference signals defines the
actual reference.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input 29
(FC 302 only)
[8] Frequency input 33
[11] Local bus reference
[20]
*
Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
3-17 Reference Source 3
Option: Function:
Select the reference input to be used for the third reference
signal. Par. 3-15, 3-16 and 3-17 define up to three different ref-
erence signals. The sum of these reference signals defines the
actual reference.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input 29
(FC 302 only)
[8] Frequency input 33
[11]
*
Local bus reference
[20] Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
3-18 Relative Scaling Reference Source
Option: Function:
Select a variable value to be added to the fixed value (defined
in par. 3-14
Preset Relative Reference ). The sum of the fixed
and variable values (labelled Y in the illustration below) is mul-
tiplied with the actual reference (labelled X in the illustration
below). This product is then added to the actual reference (X
+X*Y/100) to give the resultant actual reference.
