Danfoss FC 300

4-51 Warning Current High
Range: Function:
par.
16-37
A
*
[Par. 4-50 - par.
16-37]
Enter the I
HIGH
value. When the motor current exceeds this limit,
the display reads
Current High . The signal outputs can be pro-
grammed to produce a status signal on terminal 27 or 29 and
on relay output 01 or 02. Refer to the drawing in this section.
4-52 Warning Speed Low
Range: Function:
0 RPM
*
[0 - par. 4-13] Enter the n
LOW
value. When the motor speed exceeds this limit,
the display reads
Speed Low . The signal outputs can be pro-
grammed to produce a status signal on terminal 27 or 29 (FC
302 only) and on relay output 01 or 02 (FC 302 only).
4-53 Warning Speed High
Range: Function:
par.
4-13
RPM
*
[Par. 4-52 - par. 4-13] Enter the n
HIGH
value. When the motor speed exceeds this limit,
the display reads
Speed High . The signal outputs can be pro-
grammed to produce a status signal on terminal 27 or 29 and
on relay output 01 or 02. Programme the upper signal limit of
the motor speed, n
HIGH
, within the normal working range of the
frequency converter. Refer to the drawing in this section.
4-54 Warning Reference Low
Range: Function:
-999999
.999
*
[-999999.999 - par.
4-55]
Enter the lower reference limit. When the actual reference falls
below this limit, the display indicates
Ref Low . The signal out-
puts can be programmed to produce a status signal on terminal
27 or 29 and on relay output 01 or 02.
4-55 Warning Reference High
Range: Function:
999999.
999
*
[Par. 4-54 -
999999.999]
Enter the upper reference limit. When the actual reference ex-
ceeds this limit, the display reads Ref High. The signal outputs
can be programmed to produce a status signal on terminal 27
or 29 and on relay output 01 or 02.
4-56 Warning Feedback Low
Range: Function:
-999999
.999
*
[-999999.999 - par.
4-57]
Enter the lower feedback limit. When the feedback falls below
this limit, the display reads Feedb Low. The signal outputs can
be programmed to produce a status signal on terminal 27 or 29
and on relay output 01 or 02.
FC 300 Programming Guide 2. How to Programme
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark 91
2
