Danfoss FC 301 Operating Guide

Type designation P37K P45K P55K P75K
High/normal load
1)
HO NO HO NO HO NO HO NO
Typical shaft output [kW/(hp)] 37 (50) 45 (60) 45 (60) 55 (75) 55 (75) 75 (100) 75 (100) 90 (125)
Enclosure protection rating IP20 C3 C3 C3 C4 C4
Enclosure protection rating IP21, IP55, IP66 C1 C1 C1 C2 C2
Output current
Continuous (525–550 V) [A] 54 65 65 87 87 105 105 137
Intermittent (525–550 V) [A] 81 72 98 96 131 116 158 151
Continuous (551–600 V) [A] 52 62 62 83 83 100 100 131
Intermittent (551–600 V) [A] 78 68 93 91 125 110 150 144
Continuous kVA (550 V) [kVA] 51.4 61.9 61.9 82.9 82.9 100.0 100.0 130.5
Continuous kVA (575 V) [kVA] 51.8 61.7 61.7 82.7 82.7 99.6 99.6 130.5
Maximum input current
Continuous at 550 V [A] 49 59 59 78.9 78.9 95.3 95.3 124.3
Intermittent at 550 V [A] 74 65 89 87 118 105 143 137
Continuous at 575 V [A] 47 56 56 75 75 91 91 119
Intermittent at 575 V [A] 70 62 85 83 113 100 137 131
Additional specications
IP20 maximum cable cross-section
5)
for mains and
motor [mm
2
] ([AWG])
50 (1) 150 (300 MCM)
IP20 maximum cable cross-section
5)
for brake and load
sharing [mm
2
] ([AWG])
50 (1) 95 (4/0)
IP21, IP55, IP66 maximum cable cross-section
5)
for
mains and motor [mm
2
] ([AWG])
50 (1) 150 (300 MCM)
IP21, IP55, IP66 maximum cable cross-section
5)
for
brake and load sharing [mm
2
] ([AWG])
50 (1) 95 (4/0)
Maximum cable cross-section
2),5)
for mains disconnect
[mm
2
] ([AWG])
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM, 300
MCM, 4/0)
Estimated power loss at rated maximum load [W]
3)
740 900 900 1100 1100 1500 1500 1800
Eciency
4)
0.98 0.98 0.98 0.98
Table 8.9 Mains Supply 525–600 V P37K–P75K (FC 302 only), P37K–P75K
For fuse ratings, see chapter 8.7 Fuses and Circuit Breakers.
1) High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2) The 3 values for the maximum cable cross-section are for single core,
exible wire, and exible wire with sleeve, respectively.
3) Applies to dimensioning of frequency converter cooling. If the switching frequency is higher than the default setting, the power losses may
increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to
drives.danfoss.com/knowledge-center/energy-eciency-directive/#/
4) Eciency measured at nominal current. For energy eciency class, see chapter 8.4 Ambient Conditions. For part load losses, see
drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
5) Cable cross-section is regarded for copper cables.
Specications Operating Guide
MG33AT02 Danfoss A/S © 05/2018 All rights reserved. 39
8 8

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
