Danfoss FC 301 Operating Guide

Type designation P11K P15K P18K P22K
High/normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output at 550 V [kW/(hp)] 7.5
(10)
11
(15)
11
(15)
15
(20)
15
(20)
18.5
(25)
18.5
(25)
22
(30)
Typical shaft output at 690 V [kW/(hp)] 11
(15)
15
(20)
15
(20)
18.5
(25)
18.5
(25)
22
(30)
22
(30)
30
(40)
Enclosure protection rating IP20 B4 B4 B4 B4
Enclosure protection rating IP21, IP55 B2 B2 B2 B2
Output current
Continuous (525–550 V) [A] 14.0 19.0 19.0 23.0 23.0 28.0 28.0 36.0
Intermittent (60 s overload) (525–550 V) [A] 22.4 20.9 30.4 25.3 36.8 30.8 44.8 39.6
Continuous (551–690 V) [A] 13.0 18.0 18.0 22.0 22.0 27.0 27.0 34.0
Intermittent (60 s overload) (551–690 V) [A] 20.8 19.8 28.8 24.2 35.2 29.7 43.2 37.4
Continuous kVA (at 550 V) [kVA] 13.3 18.1 18.1 21.9 21.9 26.7 26.7 34.3
Continuous kVA (at 690 V) [kVA] 15.5 21.5 21.5 26.3 26.3 32.3 32.3 40.6
Maximum input current
Continuous (at 550 V) [A] 15.0 19.5 19.5 24.0 24.0 29.0 29.0 36.0
Intermittent (60 s overload) (at 550 V) [A] 23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Continuous (at 690 V) [A] 14.5 19.5 19.5 24.0 24.0 29.0 29.0 36.0
Intermittent (60 s overload) (at 690 V) [A] 23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Additional specications
Maximum cable cross-section
2),5)
for mains/motor,
load share, and brake [mm
2
] ([AWG])
35, 25, 25 (2, 4, 4)
Maximum cable cross-section
2),5)
for mains
disconnect [mm
2
] ([AWG])
16, 10, 10 (6, 8, 8)
Estimated power loss at rated maximum load (W)
3)
150 220 220 300 300 370 370 440
Eciency
4)
0.98 0.98 0.98 0.98
Table 8.11 B2/B4 Enclosure, Mains Supply 525–690 V IP20/IP21/IP55 - Chassis/NEMA 1/NEMA 12 (FC 302 only), P11K–P22K
Specications Operating Guide
MG33AT02 Danfoss A/S © 05/2018 All rights reserved. 41
8 8

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
