13-44 Logic Rule Boolean 3

Array [6]

Option: Function:

[19] Warning

[20] Alarm (trip)

[21] Alarm (trip lock)

[22] Comparator 0

[23] Comparator 1

[24] Comparator 2

[25] Comparator 3

[26] Logic rule 0

[27] Logic rule 1

[28] Logic rule 2

[29] Logic rule 3

[30] SL Time-out 0

[31] SL Time-out 1

[32] SL Time-out 2

[33] Digital input DI18

[34] Digital input DI19

[35] Digital input DI27

[36] Digital input DI29

[37] Digital input DI32

[38] Digital input DI33

[39] Start command

[40] Drive stopped

[41] Reset Trip

[42] Auto Reset Trip

[43] OK Key

[44] Reset Key

[45] Left Key

[46] Right Key

[47] Up Key

[48] Down Key

[50] Comparator 4

[51] Comparator 5

[60] Logic rule 4

[61] Logic rule 5

[70] SL Time-out 3

[71] SL Time-out 4

[72] SL Time-out 5

[73] SL Time-out 6

[74] SL Time-out 7

[76] Digital Input x30 2

[77] Digital Input x30 3

[78] Digital Input x30 4

[80] No Flow

[81] Dry Pump

[82] End of Curve

[83] Broken Belt

[90] ECB Drive Mode

[91] ECB Bypass Mode

[92] ECB Test Mode

[100] Fire Mode

See 13-15 RS-FF Operand S, 13-16 RS-

FF Operand R.

3.13.6 13-5* States

13-51 SL Controller Event

Array [20]

Option: Function:

Select the boolean input (TRUE or

FALSE) to dene the smart logic

controller event.

See parameter 13-02 Stop Event for

further descriptions of options and

their functions.

[0] False

[1] True

[2] Running

[3] In range

[4] On reference

[5] Torque limit

[6] Current Limit

[7] Out of current range

[8] Below I low

[9] Above I high

[10] Out of speed range

[11] Below speed low

[12] Above speed high

[13] Out of feedb. range

[14] Below feedb. low

[15] Above feedb. high

[16] Thermal warning

[17] Mains out of range

[18] Reversing
