16-86 FC Port REF 1
Range: Function:
0* [-200 -
200 ]
View the 2-byte status word (STW) sent to the
bus master. Interpretation of the status word
depends on the eldbus option installed and the
control word prole selected in
parameter 8-10 Control Prole.
3.16.7 16-9* Diagnosis Readouts
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, that is as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software le.
16-90 Alarm Word
Range: Function:
0* [0 - 4294967295 ] View the alarm word sent via the serial
communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0* [0 - 4294967295 ] View the alarm word 2 sent via the serial
communication port in hex code.
16-92 Warning Word
Range: Function:
0* [0 - 4294967295 ] View the warning word sent via the serial
communication port in hex code.
16-93 Warning Word 2
Range: Function:
0* [0 - 4294967295 ] View the warning word 2 sent via the
serial communication port in hex code.
16-94 Ext. Status Word
Range: Function:
0* [0 - 4294967295 ] Returns the extended status word sent
via the serial communication port in hex
code.
16-95 Ext. Status Word 2
Range: Function:
0* [0 - 4294967295 ] Returns the extended warning word 2
sent via the serial communication port in
hex code.
16-96 Maintenance Word
Range: Function:
0* [0 -
4294967295 ]
Readout of the preventive maintenance word.
The bits reect the status for the
programmed preventive maintenance events
in parameter group 23-1* Maintenance. 13
bits represent combinations of all the possible
items:
•
Bit 0: Motor bearings .
•
Bit 1: Pump bearings.
•
Bit 2: Fan bearings.
•
Bit 3: Valve.
•
Bit 4: Pressure transmitter.
•
Bit 5: Flow transmitter.
•
Bit 6: Temperature transmitter.
•
Bit 7: Pump seals.
•
Bit 8: Fan belt.
•
Bit 9: Filter.
•
Bit 10: Drive cooling fan.
•
Bit 11: Drive system health check.
•
Bit 12: Warranty.
•
Bit 13: Maintenance Text 0.
•
Bit 14: Maintenance Text 1.
•
Bit 15: Maintenance Text 2.
•
Bit 16: Maintenance Text 3.
•
Bit 17: Maintenance Text 4.
Parameter Descriptions Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 135
3 3
