18-12 Fire Mode Log: Date and Time
Range: Function:
Size
related*
[ 0 -
0 ]
This parameter contains an array with 10
elements. The parameter shows at which date
and time the logged event occurred. The
function relies on that the actual date and
time has been set in parameter 0-70 Date and
Time. Note: There is no built-in battery back-
up of the clock. Use an external back-up, for
example the one in the MCB 109 Analog I/O
option card. See parameter group 0–7* Clock
Settings .
3.17.3 18-3* Analog I/O
Parameters for reporting the digital and analog I/O ports.
18-30 Analog Input X42/1
Range: Function:
0* [-20 -
20 ]
Readout of the value of the signal applied to
terminal X42/1 on the analog I/O card.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-00 Terminal X42/1 Mode.
18-31 Analog Input X42/3
Range: Function:
0* [-20 -
20 ]
Readout of the value of the signal applied to
terminal X42/3 on the analog I/O card.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-01 Terminal X42/3 Mode.
18-32 Analog Input X42/5
Range: Function:
0* [-20 -
20 ]
Readout of the value of the signal applied to
terminal X42/5 on the analog I/O card.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-02 Terminal X42/5 Mode.
18-33 Analog Out X42/7 [V]
Range: Function:
0* [0 - 30 ] Readout of the value of the signal applied to
terminal X42/7 on the analog I/O card.
The value shown reects the selection in
parameter 26-40 Terminal X42/7 Output.
18-34 Analog Out X42/9 [V]
Range: Function:
0* [0 - 30 ] Readout of the value of the signal applied to
terminal X42/9 on the analog I/O card.
The value shown reects the selection in
parameter 26-50 Terminal X42/9 Output.
18-35 Analog Out X42/11 [V]
Range: Function:
0* [0 - 30 ] Readout of the value of the signal applied to
terminal X42/11 on the analog I/O card.
The value shown reects the selection in
parameter 26-60 Terminal X42/11 Output.
18-36 Analog Input X48/2 [mA]
Range: Function:
0* [-20 - 20] View the actual current measured at input X48/2.
18-37 Temp. Input X48/4
Range: Function:
0* [-500 - 500] View the actual temperature measured at input
X48/4. The temperature unit is based on the
selection in 35-00 Term. X48/4 Temperature Unit.
18-38 Temp. Input X48/7
Range: Function:
0* [-500 - 500] View the actual temperature measured at input
X48/7. The temperature unit is based on the
selection in 35-02 Term. X48/7 Temperature Unit.
18-39 Temp. Input X48/10
Range: Function:
0* [-500 - 500] View the actual temperature measured at input
X48/10. The temperature unit is based on the
selection in 35-04 Term. X48/10 Temperature
Unit.
3.17.4 18-5* Ref. & Feedb.
NOTICE
Sensorless readout requires set-up by MCT 10 Set-up
Software with sensorless specic plug-in.
18-50 Sensorless Readout [unit]
Range: Function:
0 SensorlessUnit* [-999999.999 - 999999.999
SensorlessUnit]
