26-52 Terminal X42/9 Max. Scale
See Illustration 3.30.
Range: Function:
100
%*
[0 -
200 %]
Scale the maximum output of the selected
analog signal at terminal X42/9. Set the value to
the maximum value of the voltage signal output.
Scale the output to give a voltage lower than 10
V at full scale; or 10 V at an output below 100%
of the maximum signal value. If 10 V is the
desired output current at a value between
0-100% of the full-scale output, programme the
percentage value in the parameter, that is,
50%=10 V. If a voltage between 0 and 10 V is
desired at maximum output, calculate the
percentage as follows:
that is
5V :
10V
5V
× 100 % = 200 %
26-53 Terminal X42/9 Bus Control
Range: Function:
0 %* [0 - 100 %] Holds the level of terminal X42/9 if
controlled by bus.
26-54 Terminal X42/9 Timeout Preset
Range: Function:
0 %* [0 - 100
%]
Holds the preset level of terminal X42/9.
If a bus time-out and a time-out function are
selected in parameter 26-60 Terminal X42/11
Output, the output presets to this level.
3.24.7 26-6* Analog Out X42/11
Parameters for conguring the scaling and output function
for analog output, terminal X42/11.
26-60 Terminal X42/11 Output
Option: Function:
Set the function of terminal X42/11.
[0] * No operation
[100] Output freq.
0-100
0–100 Hz, (0–10 V).
[101] Reference Min-
Max
Minimum reference - maximum
reference, (0–10 V).
[102] Feedback
+-200%
-200% to +200% of 3-03 Maximum
Reference, (0–10 V).
[103] Motor cur. 0-
Imax
0–inverter maximum current
(parameter 16-37 Inv. Max. Current), (0–10
V).
[104] Torque 0-Tlim
0–torque limit (parameter 4-16 Torque
Limit Motor Mode), (0–10 V).
[105] Torque 0-Tnom 0–motor rated torque, (0–0 V).
[106] Power 0-Pnom 0–motor rated power, (0–10 V).
26-60 Terminal X42/11 Output
Option: Function:
[107] Speed 0-
HighLim
0–speed high limit
(parameter 4-13 Motor Speed High Limit
[RPM] and parameter 4-14 Motor Speed
High Limit [Hz]), (0–10 V).
[113] Ext. Closed Loop
1
0–100%, (0–10 V).
[114] Ext. Closed Loop
2
0–100%, (0–10 V).
[115] Ext. Closed Loop
3
0–100%, (0–10 V).
[139] Bus ctrl. 0–100%, (0–10 V).
[141] Bus ctrl t.o. 0–100%, (0–10 V).
26-61 Terminal X42/11 Min. Scale
For more information, see chapter 3.8.7 6-51 Terminal 42 Output
Min Scale.
Range: Function:
0 %* [0 - 200
%]
Scale the minimum output of the selected
analog signal at terminal X42/11, as a
percentage of the maximum signal level. For
example, if 0 V is desired at 25% of the
maximum output value, programme 25%.
Scaling values up to 100% can never be higher
than the corresponding setting in
parameter 26-62 Terminal X42/11 Max. Scale.
26-62 Terminal X42/11 Max. Scale
See Illustration 3.30.
Range: Function:
100
%*
[0 -
200 %]
Scale the maximum output of the selected
analog signal at terminal X42/9. Set the value to
the maximum value of the voltage signal output.
Scale the output to give a voltage lower than 10
V at full scale; or 10 V at an output below 100%
of the maximum signal value. For example, If 10
V is the desired output current at a value
between 0-100% of the full-scale output,
programme the percentage value in the
parameter, that is, 50%=10 V. If a voltage
between 0 and 10 V is desired at maximum
output, calculate the percentage as follows:
10V
desiredmaximumvoltage
x100 %
that is
5V :
10V
5V
x100 % = 200 %
26-63 Terminal X42/11 Bus Control
Range: Function:
0 %* [0 - 100 %] Holds the level of terminal X42/11 if
controlled by bus.
Parameter Descriptions
VLT
®
HVAC Drive FC 102
206 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
33
