small steps. Depending on the motor, this parameter can
be set to 10–100% higher than the default value.
1-10 Motor Construction
Select the motor construction type.
Option: Function:
[0] * Asynchron For asynchronous motors.
[1] PM, non
salient SPM
Use for non-salient PM motors.
[5] Sync.
Reluctance
Use for synchronous reluctance motors.
NOTICE
This option has the following
rmware version limitations:
•
Version 4.2x and earlier – do
not use this option. There is
a risk of damage to the
frequency converter.
•
Version 4.3x – use this
option only when ying
start is enabled in parameter
parameter 1-73 Flying Start.
3.3.4
1-14 to 1-17 VVC
+
PM
The default control parameters for VVC
+
PM motor control
core are optimised for HVAC applications and inertia load
in the range of 50>Jl/Jm>5, where Jl is load inertia from
the application and Jm is machine inertia.
For low inertia applications (Jl/Jm<5), it is recommended
that 1-17 Voltage lter time const. is increased with a factor
of 5–10 and, in some cases, 14-08 Damping Gain Factor
should also be reduced to improve performance and
stability.
For high inertia applications (Jl/Jm>50), it is recommended
that 1-15 Low Speed Filter Time Const., 1-16 High Speed Filter
Time Const., and 14-08 Damping Gain Factor are increased
to improve performance and stability.
For high load at low speed (<30% of rated speed), it is
recommended that 1-17 Voltage
lter time const. is
increased due to non-linearity in the inverter at low speed.
1-14 Damping Gain
Range: Function:
120
%*
[0 -
250 %]
The damping gain stabilises the PM machine in
order to run the PM machine smooth and stable.
The value of damping gain controls the dynamic
performance of the PM machine. High damping
gain gives low dynamic performance, and low
damping gain gives high dynamic performance.
The dynamic performance is related to the
machine data and load type. If the damping gain
is too high or low, the control becomes unstable.
1-15 Low Speed Filter Time Const.
Range: Function:
Size
related*
[0.01 -
20 s]
High-pass lter damping time constant
determines the response time to load
steps. Obtain quick control through a
short damping time constant. However,
if this value is too low, the control
becomes unstable. This time constant is
used below 10% rated speed.
1-16 High Speed Filter Time Const.
Range: Function:
Size
related*
[0.01 -
20 s]
High-pass lter damping time constant
determines the response time to load
steps. Obtain quick control through a
short damping time constant. However,
if this value is too low, the control
becomes unstable. This time constant is
used above 10% rated speed.
1-17 Voltage lter time const.
Range: Function:
Size
related*
[0.001 - 1
s]
Machine supply voltage lter time
constant is used for reducing the
inuence of high-frequency ripples and
system resonances in the calculation of
machine supply voltage. Without this
lter, the ripples in the currents can
distort the calculated voltage and aect
the stability of the system.
3.3.5 1-2* Motor Data
This parameter group contains input data from the
nameplate on the connected motor.
NOTICE
Changing the value of these parameters aects the
setting of other parameters.
NOTICE
Parameter 1-20 Motor Power [kW], parameter 1-21 Motor
Power [HP], parameter 1-22 Motor Voltage, and
parameter 1-23 Motor Frequency have no eect when
parameter 1-10 Motor Construction is set to [1] PM, non-
salient SPM, [2] PM, salient IPM, [5] Sync. Reluctance.
Parameter Descriptions
VLT
®
HVAC Drive FC 102
40 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
