Danfoss Series 90

Series 90 Master Model
Code (continued)
L Shaft Options
042 055 075 100 130 180 250
C3 splined shaft, 15 teeth, pitch = 16 / 32 O
C6 splined shaft, 21 teeth, pitch = 16 / 32 O O O
C7 splined shaft, 23 teeth, pitch = 16 / 32 O O
C8 splined shaft, 27 teeth, pitch = 16 / 32 O O O
F1 splined shaft, 13 teeth, pitch = 8 / 16 O O O O
S1 splined shaft, 14 teeth, pitch = 12/24 O O O
G1 splined shaft , 25 teeth, pitch = 20 / 40 O O
T1 tapered shaft diameter = 34,925 MM O O
T6 tapered shaft diameter = 38,100 MM O O
T8 tapered shaft diameter = 25,400 MM O
T4 tapered shaft diameter = 44,450 MM O
H Charging System
042 055 075 100 130 180 250
B nominal f ow = 11 cc / rev O O
C nominal f ow = 14 cc / rev O O O
D nominal f ow = 17 cc / rev O O O
E nominal f ow = 20 cc / rev O O
F nominal f ow = 26 cc / rev O O
H nominal f ow = 34 cc / rev O O
J nominal f ow = 47 cc / rev O O
K nominal f ow = 65 cc / rev O
L
external charge pump with internal charge pressure relief valve for units with auxiliary
mounting pad
O O O O O O O
N
external charge pump with internal charge pressure relief valve for units with no
auxiliary mounting pad
O O O O O O
R Size M P J G N F L H T W Y Z K
S90
Technical Information Series 90 Axial Piston Pumps
Master Model Code
520L0603 • Rev 0804 • March 2016 23
