Series 90 Master Model
Code (continued)
R Size M P J G N F L H T W Y Z K
S90
T Control Orif ce Options
MDC
inlet P drain TA drain TB servo A servo B 042 055 075 100 130 180 250
00 n/o 1.6 *) 1.6 *) n/o n/o O O O O O O O
03 0.81 1.6 *) 1.6 *) n/o n/o O O O O O O O
05 1.37 1.6 *) 1.6 *) n/o n/o O O O O O O O
C5 0.81 1.4 1.4 n/o n/o O O O O O O O
C6 1.02 1.4 1.4 n/o n/o O O O O O O O
*) No orif ce installed in control, orif ce hole in contro spool
If further orif ce options are needed, please contact your Danfoss representative
EDC
inlet P drain TA drain TB servo A servo B 042 055 075 100 130 180 250
00 (1) n/o 1.3 1.3 n/o n/o O O O O O O O
03 (1) 0.81 1.3 1.3 n/o n/o O O O O O O O
05 (1) 1.37 1.3 1.3 n/o n/o O O O O O O O
33 0.81 n/o n/o n/o n/o O O O O O O O
FNR
inlet P drain T servo A servo B 042 055 075 100 130 180 250
G1 n/o 1.2 n/o n/o O O O O O O O
G4 0.46 1.2 n/o n/o O O O O O O O
G8 0.66 1.2 n/o n/o O O O O O O O
GB 0.81 1.2 n/o n/o O O O O O O O
GD 1.57 1.2 n/o n/o O O O O O O O
HDC
inlet P drain TA drain TB servo A servo B 042 055 075 100 130 180 250
00 (1) n/o 1.3 1.3 n/o n/o O O O O O O O
03 (1) 0.81 1.3 1.3 n/o n/o O O O O O O O
05 (1) 1.37 1.3 1.3 n/o n/o O O O O O O O
NFPE
inlet P drain T servo A servo B 042 055 075 100 130 180 250
B1 n/o 1.5 n/o n/o O O O O O O O
B2 n/o n/o 1.2 1.2 O O O O O O O
B6 n/o n/o n/o n/o O
Technical Information Series 90 Axial Piston Pumps
Master Model Code
24 520L0603 • Rev 0804 • March 2016
