Danfoss Series 90

Auxiliary mounting pad – options AB, BC, BB
146
[5.75]
146
[5.75]
4 threads
1/2-13UNC-2B
22 [0.87] deep
View "X"
146
([5.75]
146
[5.75]
4 threads
1/2-13UNC-2B
22 [0.87] deep
View "X"
106.38
[4.188]
106.38
[4.188]
4 threads
3/8-16UNC-2B
17.8 [0.70] deep
View "X"
SAE B-B, option BB
300.37
[11.83]
282.92
[11.14]
For O-ring
Ø94.92 x 2.62
[Ø3.737 x 0.103]
"X"
Coupling spline data:
Pitch diameter = 23.8125 [0.9375]
Pressure Angle = 30°
Number of teeth = 15
Pitch = 16/32
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 15. 2 [0.598]
Ø101.65
[Ø4.002]
+ 0.05 - 0.00
[+0.002] [- 0.000]
30.8
[1.21]
300.37
[11.83]
282.92
[11.14]
for O-ring
Ø94.92 x 2.62
[Ø3.737 x 0.103]
"X"
Coupling spline data:
Pitch diameter = 20.638 [0.8125]
Pressure Angle = 30°
Number of teeth = 13
Pitch = 16/32
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 25.5 [1.0]
SAE B, option BC
20.5
[0.81]
Ø101.64
[Ø4.002]
+ 0.05 0
[+0.002] [- 0.000]
301.85
[11.88]
288
[11.34]
for O-ring
Ø82.22 x 2.62
[Ø3.237 x 0.103]
Coupling spline data:
Pitch diameter = 14.288 [0.5625]
Pressure angle = 30°
Number of teeth = 9
Pitch = 16/32
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 33.5 [1.32]
"X"
18
[0.71]
Ø82.6
[Ø3.252]
+ 0.13 0
[+0.005] [- 0.000]
SAE A, option AB
2
2
2
M1
M2
M1
M2
M1
M2
M5
M5
M5
P102 041
Technical Information Series 90 Axial Piston Pumps
Installation Drawings
520L0603 • Rev 0804 • March 2016 51
