P108 501E
71
[2.8]
8
[0.32]
28.1
[1.106]
Washer
DIN EN ISO 7089-300
Self-lock nut (DIN 985)
M18 x 1.5
[0.709]
25.4
[1.00]
Cone 1:8 per SAE J501
108.6
[4.28]
7.9
[0.311]
38
[1.515]
Coupling must not protude beyond this surface
108.6
[4.28]
Option C3 ISO 3019-1 Flange Outer
Diameter 25mm -4mm (SAE B-B, 15 tooth)
21.34
[0.84]
25.0
[0.98]
25.4
[1.00]
Cone flange must not
protrude beyond this point
*
* Minimum active spline length
for the specified torque ratings
Option T8
Refer to (torque - tapered shafts) table
page 42 for torque information
