Danfoss Series 90 User Manual

Auxiliary mounting pads, SAE AB, SAE BC, SAE CD
M3
M2
M10
M1
B
M4
M5
M3
M2
M10
M1
B
A
M3
M2
M10
M1
B
A
SAE B, Option BC
378,3
(14.89)
360,9
(14.21)
for O-Ring
ø94.92 x 2.62
(3.737 Dia x 0.103)
"X"
ø101,65
(4.002 Dia)
COUPLING SPLINE DATA:
Pitch Dia = 20,6375 (.8125)
Pressure Angle = 30
Number of teeth = 13
Pitch = 16/32
ANSI B92.1-1970, Class 6,
Fillet Root Side Fit
Length of spline = 29,51 (1.16)
+ 0,13 0
(+.005) (- .000)
17,66
(.70)
View "X"
4 Threads
1/2-13UNC-2B
22 (.87) deep
146
(5.75)
146
(5.75)
SAE C, Option CD
View "X"
6 Threads
1/2-13UNC-2B
22 (.87) deep
114,5
(4.51)
114,5
(4.51)
181
(7.13)
380,27
(14.97)
363,47
(14.31)
for O-Ring
ø120.32 x 2.62
(4.737 Dia x 0.103)
"X"
ø127,03
(5.001 Dia)
COUPLING SPLINE DATA:
Pitch Dia = 29,6333 (1.167)
Pressure Angle = 30
Number of teeth = 14
Pitch = 12/24
ANSI B92.1-1970, Class 6,
Fillet Root Side Fit
Length of spline = 18,97 (.747)
+ 0,13 0
(+.005) (- .000)
30,73
(1.21)
2
2
SAE A, Option AB
379,69
(14.95)
366,02
(14.41)
for O-Ring
ø82.22 x 2.62
(3.237 Dia x 0.103)
COUPLING SPLINE DATA:
Pitch Dia = 14,288 (.5625)
Pressure Angle = 30
Number of teeth = 9
Pitch = 16/32
ANSI B92.1-1970, Class 6,
Fillet Root Side Fit
Length of spline = 37,13 (1.46)
"X"
ø82,6
(3.252 Dia)
+ 0,13 0
(+.005) (- .000)
15,13
(.60)
View "X"
4 Threads
3/8-16UNC-2B
17 (.67) deep
106,375
(4.188)
106,375
(4.188)
2
A
M4
M5
M4
M5
P106 645E
Technical Information Series 90 Axial Piston Pumps
Installation Drawings
520L0603 • Rev 0804 • March 2016 67
