Auxiliary mounting pad - options AB, BC, CD, DE, EF, EG, BB
477.1
[18.78]
460.4
[18.13]
For O-ring
Ø 120.32 x 2.62
[Ø 4.737 x 0.103]
"X"
Ø 127.03
[Ø 5.001]
Coupling spline data:
Pitch diameter = 29.6333 [1.167]
Pressure angle = 30°
Number of teeth = 14
Pitch = 12/24
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 22.1 [0.87]
+ 0.13
- 0.00
[+0.005]
[- 0.000]
30.5
[1.20]
SAE B, option BC
475.1
[18.70]
457.4
[18.01]
For O-ring
Ø 94.92 x 2.62
[Ø 3.737 x 0.103]
"X"
Ø 101.65
[Ø 4.002]
Coupling spline data:
Pitch diameter = 20.6375 [0.8125]
Pressure angle = 30°
Number of teeth = 13
Pitch = 16/32
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 29.5 [1.16]
+ 0.13
- 0.00
[+0.005]
[- 0.000]
17.5 [0.69]
SAE C, option CD
6 threads
1/2-13UNC-2B
22 [0.87] deep
View "X"
114.5
[4.51]
114.5
[4.51]
181
[7.13]
463.90
[18.26]
450.30
[17.73]
Coupling spline data:
Pitch diameter = 14.288 [0.5625]
Pressure angle = 30°
Number of teeth =
9
Pitch = 16/32
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 17.8 [0.70]
For O-ring
Ø 82.22 x 2.62
[Ø 3.237 x 0.103]
+ 0.13
- 0.00
[+ 0.005]
[- 0.000]
Ø 82.6
[Ø 3.252]
15
[0.59]
"X"
SAE A, option AB
View "X"
4 threads
3/8-16UNC-2B
17.8 [0.70] deep
106.375
[4.188]
106.375
[4.188]
4 threads
1/2-13UNC-2B
22 [0.87] deep
View "X"
146
[5.75]
146
[5.75]
P102 062
Technical Information Series 90 Axial Piston Pumps
Installation Drawings
520L0603 • Rev 0804 • March 2016 79
