Danfoss Series 90 User Manual

Auxiliary mounting pad – options AB, BC, CD, DE EF, EG, BB
View "X"
SAE E, option EF
View "X"
SAE E, option EG
2
SAE D, option DE
"X"
485.8
[19.13]
469.1
[18.47]
For O-ring
Ø 153 x 3.0
[Ø 6.02 x 0.118]
Coupling spline data:
Pitch diameter = 41.275 [1.625]
Pressure angle = 30°
Number of teeth = 13
Pitch = 8/16
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 25.9 [1.02]
+ 0.13 - 0.00
[+0.005] [- 0.000]
Ø 152.45
[Ø 6.002]
49.9
[1.96]
2
494.1
[19.45]
469.1
[18.47]
For O-ring
Ø 158.42 x 2.62
[Ø 6.24 x 0.10]
"X"
Coupling spline data:
Pitch diameter = 41.275 [1.625]
Pressure angle = 30
Number of teeth = 13
Pitch = 8/16
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 25.9 [1.02]
48.5
[1.91]
Ø 165.15
[Ø 6.501]
+ 0.13 - 0.00
[+0.005] [- 0.000]
2
469.1
[18.47]
For O-ring
Ø 164.77 x 2.62
[Ø 6.48 x 0.10]
"X"
Coupling spline data:
Pitch diameter = 42.862 [1.687]
Pressure angle = 30°
Number of teeth = 27
Pitch = 16/32
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 28.5 [1.12]
46.5
[1.83]
Ø 165.15
[Ø 6.501]
+ 0.13 - 0.00
[+0.005] [- 0.000]
494.1
[19.45]
B
M2
S
a
M1
M3
A
M10
M5
M4
4 threads
3/4-10UNC-2B
41 [1.61] deep
161.6
[6.36]
161.6
[6.36]
B
M2
S
a
M1
M3
A
M10
M5
M4
4 threads
3/4-10UNC-2B
41 [1.61] deep
224.5
[8.84]
224.5
[8.84]
B
M2
S
a
M1
M3
A
M10
M5
M4
4 threads
3/4-10UNC-2B
41 [1.61] deep
224.5
[8.84]
224.5
[8.84]
P102 063
Technical Information Series 90 Axial Piston Pumps
Installation Drawings
80 520L0603 • Rev 0804 • March 2016
