PNU # Parameter description Factory setting 4-set-up Conv.
index
Data
type
302 Digital input, term. 18 Start Yes 0 5
303 Digital input, term. 19 Reversing Yes 0 5
304 Digital input, term. 27 Reset and coast inverse Yes 0 5
305 Digital input, term. 29 Jog Yes 0 5
307 Digital input, term. 33 No function Yes 0 5
308 Term. 53, analog input voltage Reference Yes 0 5
309 Term. 53, min scaling 0.0 V Yes -1 6
310 Term. 53, max scaling 10.0 V Yes -1 6
314 Term. 60, analog input current No function Yes 0 5
315 Term. 60, min scaling 0.0 mA Yes -4 6
316 Term. 60, max scaling 20.0 mA Yes -4 6
317 Time out 10 s Yes -1 5
318 Function after time-out No function Yes 0 5
319 Term. 42, analog output 0-I
MAX
= 0-20 mA Yes 0 5
323 Relay output Control ready Yes 0 5
327 Pulse ref./FB 5000 Hz Yes 0 7
341 Term. 46 digital output Control ready Yes 0 5
342 Term. 46 Max. pulse output 5000 Hz Yes 0 6
343 Precise stop function Normal ramp stop Yes 0 5
344 Counter value 100000 pulses Yes 0 7
349 Speed comp delay 10 ms Yes -3 6
Table 5.20 Factory Settings for Parameters 302-349
4-Set-up
Yes means that the parameter can be programmed
individually in each of the 4 set-ups, that is, one single
parameter can have 4 different data values. No means that
the data value is the same in all set-ups.
Conversion index
This number refers to a conversion factor to be used when
writing or reading via serial communication with a
frequency converter.
See chapter 4.7.4 Data Character (Byte) for more
information.
Data type
Data type shows the type and length of the telegram.
Data type Description
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Text string
Table 5.21 Data Type
All about VLT 2800
Design Guide
MG27E402 Danfoss A/S © Rev. May/2014 All rights reserved. 151
5 5
