Danfoss VLT 2800 Design Guide

3.4.2 Pre-fuses
For all unit types, fit external pre-fuses in the mains supply to the frequency converter. For UL/cUL applications with a mains
voltage of 200-240 V, use pre-fuses type Bussmann KTN-R (200-240 V) or Ferraz Shawmut type ATMR (max. 30A). For UL/cUL
applications with a mains voltage of 380-480 V, use pre-fuses type Bussmann KTS-R (380-480 V).
Alternative fuses 380-500 V drives
VLT 2800 Bussman
n
E52273
Bussmann
E4273
Bussmann
E4273
Bussman
n
E4273
Bussmann
E4273
Bussman
n
E4273
SIBA
E180276
Little Fuse
E81895
Ferraz-
Shawmut
E163267/
E2137
Ferraz-
Shawmut
E163267/
E2137
RK1/JDDZ J/JDDZ T/JDDZ CC/JDDZ CC/JDDZ CC/JDDZ RK1/JDDZ RK1/JDDZ CC/JDDZ RK1/JDDZ
2805-
2822
KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20 5017906-020 KLS-R20 ATM-R25 A6K-20R
2855-
2875
KTS-R25 JKS-25 JJS-25 5017906-025 KLS-R25 ATM-R20 A6K-25R
2880-
2882
KTS-R50 JKS-50 JJS-50 5014006-050 KLS-R50 - A6K-50R
Alternative Fuses 200-240 V drives
VLT 2800 Bussman
n
E52273
Bussmann
E4273
Bussmann
E4273
SIBA
E180276
Little Fuse
E81895
Ferraz-
Shawmut
E163267/
E2137
Ferraz-
Shawmut
E163267/
E2137
RK1/JDDZ J/JDDZ T/JDDZ RK1/JDDZ RK1/JDDZ CC/JDDZ RK1/JDDZ
2803-2822 KTN-R20 JKS-20 JJN-20 5017906-020 KLS-R20 ATM-R25 A6K-20R
2840 KTN-R25 JKS-25 JJN-25 5017906-025 KLS-R25 ATM-R20 A6K-25R
Table 3.2 Prefuses for UL application /cUL
3.4.3
Mains Connection
WARNING
At 1x220-240 V the neutral wire must be attached to
terminal N
(L2)
and the phase wire must be connected to
terminal L1
(L1)
.
No. N
(L2)
L1
(L1) (L3)
Mains voltage 1x220-240 V
N L1
No. 95 Ground connection
Table 3.3 Mains Connection - 1x220-240 V
No.
N
(L2)
L1
(L1) (L3)
Mains voltage 3x220-240 V
L2 L1 L3
No. 95 Ground connection
Table 3.4 Mains Connection - 3x220-240 V
No.
91 92 93 Mains voltage 3x380-480 V
L1 L2 L3
No. 95 Ground connection
Table 3.5 Mains Connection - 3x380-480 V
WARNING
Ensure that the mains voltage fits the mains voltage of
the frequency converter, which can be seen from the
nameplate.
WARNING
Do not connect 400 V units with RFI-filters to mains
supplies in which the voltage between phase and
ground is more than 300 V. For the IT mains and the
delta ground, the mains voltage can exceed 300 V
between phase and ground. Units with type code R5 can
be connected to mains supplies with up to 400 V
between phase and ground.
See chapter 5.1.1 Galvanic Isolation (PELV) for details on
correct dimensioning of cable cross-section.
3.4.4
Motor Connection
Connect the motor to terminals 96, 97, 98. Connect ground
to terminal 99.
See chapter 5.3 General Technical Data for correct
dimensioning of cable cross-section.
Installation Design Guide
48 Danfoss A/S © Rev. May/2014 All rights reserved. MG27E402
