Danfoss VLT AQUA FC 202 Design Guide

•
•
•
•
•
•
RFI lter type
Conducted emission
Radiated emission
0.37–7.5 kW, 380–
480 V
T4
No
No
5 (16.4)
No
No
Yes
11–90 kW, 380–
480 V
(2)
T4
No
No
25 (82)
No
No
Yes
7.5 kW, 380–480 V
S4
No
No
25 (82)
No
No
Yes
11–30 kW, 525–
690 V
(2)(3)
T7
No
No
25 (82)
No
No
Yes
37–90 kW, 525–
690 V
(2)(4)
T7
No
No
25 (82)
No
No
Yes
H3
FC 202
0.25–45 kW, 200–
240 V
T2
10 (32.8)
50 (164)
50 (164)
No
Yes
Yes
0.37–90 kW, 380–
480 V
T4
10 (32.8)
50 (164)
50 (164)
No
Yes
Yes
H4
FC 202
1.1–30 kW, 525–
690 V
(3)
T7
No
100 (328)
100 (328)
No
Yes
Yes
37–90 kW, 525–
690 V
(4)
No
150 (492)
150 (492)
No
Yes
Yes
Hx
(5)
FC 202
1.1–90 kW, 525–
600 V
T6
No
No
No
No
No
No
15–22 kW, 200–
240 V
S2
No
No
No
No
No
No
11–37 kW, 380–
480 V
S4
No
No
No
No
No
No
1
100 m (328 ft) for phase-neutral, 150 m (492 ft) for phase-to-phase (but not from TT or TN). Single-phase drives are not intended for 2-phase supply
from a TT or TN network.
2
T7, 37–90 kW complies with class A group 1 with 25 m (82 ft) motor cable. Some restrictions for the installation apply (contact Danfoss for details).
3
Enclosure size B2.
4
Enclosure size C2.
5
Hx versions can be used according to EN/IEC 61800-3 category C4.
Hx, H1, H2, H3, H4, or H5 is dened in the type code positions 16–17 for EMC lters.
H1: Integrated EMC lter. Fullls EN 55011 Class A1/B and EN/IEC 61800-3 Category 1/2.
H2: A limited RFI lter only containing capacitors and without a common-mode coil. Fullls EN 55011 Class A2 and EN/IEC
61800-3 Category 3.
H3: Integrated EMC lter. Fullls EN 55011 Class A1/B and EN/IEC 61800-3 Category 1/2.
H4: Integrated EMC lter. Fullls EN 55011 Class A1 and EN/IEC 61800-3 Category 2.
H5: Marine versions. Ruggedized version, fullls the same emission levels as H2 versions.
AJ300847815559en-000101 / 130R0337 | 147Danfoss A/S © 2020.09
Electrical Installation
Considerations
VLT® AQUA Drive FC 202
Design Guide
