- with full output power of typical EFF2 motors (up to 90% output
current)
Maximum 50° C (122° F)
(1)
- at full continuous FC output current
Maximum 50° C (122° F)
(1)
Minimum ambient temperature during full-scale operation
0 °C (32 °F)
Minimum ambient temperature at reduced speed performance
-10 °C (14 °F)
Temperature during storage/transport
-25 to +65/70 °C (-13 to +149/158 °F)
Maximum altitude above sea level without derating
1000 m (3280 ft)
Maximum altitude above sea level with derating
3000 m (9843 ft)
EMC standards, Emission
EN 61800-3
EMC standards, Immunity
EN 61800-3
Energy eciency class
(2)
IE2
1
For more information, see the Derating section in the design guide.
2
Determined according to 61800-9-2 at:
Rated load.
90% rated frequency.
Switching frequency factory setting.
Switching pattern factory setting.
MyDrive® ecoSmart
™
provides eciency and part loss data for the drive according to 61800-3.
8.5 Cable Specications
8.5.1 Cable Lengths and Cross-sections for Control Cables
Maximum motor cable length, shielded/armored
150 m (492 ft)
Maximum motor cable length, unshielded/unarmored
300 m (984 ft)
Maximum cross-section to motor, mains, load sharing, and
brake
(1)
Maximum cross-section to control terminals, rigid wire
1.5 mm
2
/16 AWG
Maximum cross-section to control terminals, exible wire
1 mm
2
/18 AWG
Maximum cross-section to control terminals, cable with enclosed
core
0.5 mm
2
/20 AWG
Minimum cross-section to control terminals
0.25 mm
2
/24 AWG
1
See electrical data tables in 8.1.1 Mains Supply 1x200–240 V AC to 8.1.6 Mains Supply 3x525–690 V AC for more information.
It is mandatory to ground the mains connection properly using T95 (PE) of the frequency converter. The ground connection cable
cross-section must be at least 10 mm
2
(8 AWG) or 2 rated mains wires terminated separately according to EN 50178. Use unshielded
cable.
8.6 Control Input/Output and Control Data
8.6.1 Digital Inputs
Programmable digital inputs
4 (6)
Terminal number
18, 19, 27
(1)
, 29
(1)
, 32, 33
Logic
PNP or NPN
Voltage level
0–24 V
Voltage level, logic 0 PNP
<5 V DC
Voltage level, logic 1 PNP
>10 V DC
Voltage level, logic 0 NPN
>19 V DC
Voltage level, logic 1 NPN
<14 V DC
AJ300847815559en-000101 / 130R0337 | 91Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Design Guide
