Danfoss VLT AQUA FC 202 Design Guide

Flat-pack IP65 for horizontal conveyors
P5K5
5.5 (7.5)
22.5
28.7
40/200
7
2 x 175U0996
13.2.9.4 Order Numbers for Brake Resistors, T4, Horizontal Braking 10% Duty Cycle
Table 136: Order Numbers for Brake Resistors, T4, Horizontal Braking 10% Duty Cycle
FC 202
Horizontal braking 10% duty cycle
Drive data
Brake resistor data
Installation
Danfoss part numbers
Mains
type
P
m
[kW]
R
min
[Ω]
R
br.nom
[Ω]
R
rec
[Ω]
P
br.cont
[kW]
Wire IP54
Screw ter-
minal IP65
Screw ter-
minal IP20
Bolt con-
nection
IP20
Cable
cross-
section
[mm
2
(AWG)]
Ther-
mo
relay
[A]
T4
0.37
(0.50)
1000
1864.2
1200
0.100
175U3000
–
–
–
1.5 (16)
0.3
T4
0.55
(0.75)
1000
1246.3
1200
0.100
175U3000
–
–
–
1.5 (16)
0.3
T4
0.75
(1.0)
620
910.2
850
0.100
175U3001
–
–
–
1.5 (16)
0.4
T4
1.1
(1.5)
546
607.3
630
0.100
175U3002
–
–
–
1.5 (16)
0.4
T4
1.5
(2.0)
382
437.3
410
0.100
175U3004
–
–
–
1.5 (16)
0.5
T4
2.2
(3.0)
260
293.3
270
0.200
175U3007
–
–
–
1.5 (16)
0.8
T4
3.0
(4.0)
189
212.7
200
0.200
175U3008
–
–
–
1.5 (16)
0.9
T4
4.0
(5.0)
135
157.3
145
0.300
175U3300
–
–
–
1.5 (16)
1.3
T4
5.5
(7.5)
99
113.3
110
0.450
175U3335
175U3450
175U3449
–
1.5 (16)
1.9
T4
7.5 (10)
72
82.4
80
0.570
175U3336
175U3452
175U3451
–
1.5 (16)
2.5
T4
11 (15)
50
55.3
56
0.680
175U3337
175U3027
175U3028
–
1.5 (16)
3.3
T4
15 (20)
36
40.3
38
1.130
175U3338
175U3034
175U3035
–
1.5 (16)
5.2
T4
18.5
(25)
27
32.5
28
1.400
175U3339
175U3039
175U3040
–
1.5 (16)
6.7
T4
22 (30)
20.3
27.2
22
1.700
175U3340
175U3047
175U3048
–
1.5 (16)
8.3
T4
30 (40)
18
19.8
19
2.200
175U3357
175U3049
175U3050
–
1.5 (16)
10.1
T4
37 (50)
13.4
16
14
2.800
175U3341
175U3055
175U3056
–
2.5 (14)
13.3
T4
45 (60)
10.8
13.1
12
3.200
175U3359
175U3061
175U3062
–
2.5 (14)
15.3
T4
55 (75)
8.8
10.7
9.5
4.200
–
175U3065
175U3066
–
4 (12)
20
AJ300847815559en-000101 / 130R0337188 | Danfoss A/S © 2020.09
How to Order a Drive
VLT® AQUA Drive FC 202
Design Guide
