Danfoss VLT AQUA FC 202 Design Guide

Flat-pack IP65 for horizontal conveyors
P4K0
4.0 (5.0)
135
157.3
300/200
10
2 x 175U0985
P5K5
5.5 (7.5)
99
113.3
130/200
7
2 x175U0990
P7K5
7.5 (10)
72
82.4
80/240
6
2 x 175U0990
13.2.9.7 Order Numbers for Brake Resistors, T6, Horizontal Braking 10% Duty Cycle
Table 139: Order Numbers for Brake Resistors, T6, Horizontal Braking 10% Duty Cycle
FC 202
Horizontal braking 10% duty cycle
Drive data
Brake resistor data
Installation
Danfoss part numbers
Mains
type
P
m
[kW]
R
min
[Ω]
R
br.nom
[Ω]
R
rec
[Ω]
P
br.cont
[kW]
Wire IP54
Screw ter-
minal IP65
Screw ter-
minal IP20
Bolt con-
nection
IP20
Cable
cross-
section
[mm
2
(AWG)]
Ther-
mo
relay
[A]
T6
0.75
(1.0)
620
1329.7
1200
0.100
175U3000
–
–
–
1.5 (16)
0.3
T6
1.1
(1.5)
620
889.1
850
0.100
175U3001
–
–
–
1.5 (16)
0.4
T6
1.5
(2.0)
550
642.7
570
0.100
175U3003
–
–
–
1.5 (16)
0.4
T6
2.2
(3.0)
380
431.1
415
0.200
175U3005
–
–
–
1.5 (16)
0.7
T6
3.0
(4.0)
260
312.5
270
0.200
175U3007
–
–
–
1.5 (16)
0.8
T6
4.0
(5.0)
189
231.6
200
0.300
175U3342
–
–
–
1.5 (16)
1.1
T6
5.5
(7.5)
135
166.6
145
0.450
175U3343
175U3012
175U3013
–
1.5 (16)
1.7
T6
7.5
(10)
99
121.1
100
0.570
175U3344
175U3136
175U3137
–
1.5 (16)
2.3
T6
11
(15)
69
81.6
72
0.680
175U3345
175U3456
175U3455
–
1.5 (16)
2.9
T6
15
(20)
48.6
59.4
52
1.130
175U3346
175U3458
175U3457
–
1.5 (16)
4.4
T6
18.5
(25)
35.1
47.9
38
1.400
175U3347
175U3460
175U3459
–
1.5 (16)
5.7
T6
22
(30)
27
40.1
31
1.700
175U3348
175U3037
175U3038
–
1.5 (16)
7.0
T6
30
(40)
22.5
29.2
27
2.200
175U3349
175U3043
175U3044
–
1.5 (16)
8.5
T6
37
(50)
17.1
23.6
19
2.800
175U3350
175U3462
175U3461
–
2.5 (14)
11.4
AJ300847815559en-000101 / 130R0337192 | Danfoss A/S © 2020.09
