Danfoss VLT AQUA FC 202 Design Guide

Type designation
P11K
P15K
P18K
P22K
P30K
P37K
Protection ratings IP21, IP55, IP66 maxi-
mum cable cross-section
(2)
for mains,
brake, and load sharing [mm
2
(AWG)]
16, 10, 10 (6, 8, 8)
38, –, – (2, –, –)
Protection ratings IP21, IP55, IP66 maxi-
mum cable cross-section
(2)
for motor
[mm
2
(AWG)]
10, 10, – (8, 8, –)
35, 25, 25 (2, 4, 4)
Maximum cable crosssection
(2)
for mains
disconnect [mm
2
(AWG)]
16, 10, 10 (6, 8, 8)
50, 35, 35 (1, 2, 2)
Estimated power loss
(3)
at rated maxi-
mum load [W]
(4)
220
300
220
300
300
370
370
440
440
600
600
740
Eciency
(5)
0.98
1
High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2
The 3 values for the maximum cable cross-section are for single core, exible wire, and exible wire with sleeve, respectively.
3
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and
typical control card power consumptions are included. For more detailed eciency values and part load losses according IEC/EN 61800-9-2 refer to
mydrive ecosmart on
www. danfoss.com. For eciency class see 8.4.1 Environment.
4
Eciency measured at nominal current. For more detailed eciency values and part load losses according IEC/EN 61800-9-2 refer to mydrive ecos-
mart on
www. danfoss.com. For eciency class see 8.4.1 Environment.
5
Measured using 5 m (16 ft) shielded motor cables at rated load and rated frequency. For more detailed eciency values and part load losses ac-
cording IEC/EN 61800-9-2 refer to mydrive ecosmart on
www. danfoss.com. For eciency class see 8.4.1 Environment.
Table 38: Mains supply 3x525–600 V AC, P45K–P90K
Type designation
P45K
P55K
P75K
P90K
High/normal overload
(1)
HO
NO
HO
NO
HO
NO
HO
NO
Typical shaft output [kW]
37
45
45
55
55
75
75
90
Typical shaft output [hp]
50
60
60
75
75
100
100
125
Protection rating IP20/Chassis
C3
C3
C4
C4
Protection rating IP21/Type 1
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
C1
C1
C2
C2
Output current
Continuous (3x525–550 V) [A]
54
65
65
87
87
105
105
137
Intermittent (3x525–550 V) [A]
81
72
98
96
131
116
158
151
Continuous (3x525–600 V) [A]
52
62
62
83
83
100
100
131
Intermittent (3x525–600 V) [A]
78
68
93
91
125
110
150
144
Continuous kVA at 525 V [kVA]
51.4
61.9
61.9
82.9
82.9
100
100
130.5
Continuous kVA at 575 V [kVA]
51.8
61.7
61.7
82.7
82.7
99.6
99.6
130.5
Maximum input current
Continuous at 550 V [A]
49
59
59
78.9
78.9
95.3
95.3
124.3
Intermittent at 550 V [A]
74
65
89
87
118
105
143
137
