Danfoss VLT AutomationDrive FC 301 Operating Guide

Type designation
P15K
P18K
P22K
P30K
P37K
Efficiency
(3)
0.96
0.97
0.97
0.97
0.97
1
High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and
typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to Danfoss
MyDrive® ecoSmart website.
3
Efficiency measured at nominal current. For energy efficiency class, see
8.4 Ambient Conditions. For part load losses, see Danfoss MyDrive® ecoS-
mart website.
8.1.2 Mains Supply 380–500 V
Table 32: Mains Supply 380–500 V (FC 302), 380–480 V (FC 301), PK37–P7K5
Type designation
PK37
PK55
PK75
P1K1
P1K5
P2K2
P3K0
P4K0
P5K5
P7K7
Typical shaft output
[kW/(hp)], high over-
load
0.37 (0.5)
0.55
(0.75)
0.75 (1.0)
1.1 (1.5)
1.5 (2.0)
2.2 (3.0)
3.0 (4.0)
4.0 (5.0)
5.5 (7.5)
7.5 (10)
Enclosure protection
rating IP20 (FC 301
only)
A1
A1
A1
A1
A1
–
–
–
–
–
Enclosure protection
rating IP20, IP21
A2
A2
A2
A2
A2
A2
A2
A2
A3
A3
Enclosure protection
rating IP55, IP66
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
Output current high overload 160% for 1 minute
Shaft output [kW/
(hp)]
0.37 (0.5)
0.55
(0.75)
0.75 (1.0)
1.1 (1.5)
1.5 (2.0)
2.2 (3.0)
3.0 (4.0)
4.0 (5.0)
5.5 (7.5)
7.5 (10)
Continuous (380–
440 V) [A]
1.3
1.8
2.4
3.0
4.1
5.6
7.2
10
13
16
Intermittent (380–
440 V) [A]
2.1
2.9
3.8
4.8
6.6
9.0
11.5
16
20.8
25.6
Continuous (441–
500 V) [A]
1.2
1.6
2.1
2.7
3.4
4.8
6.3
8.2
11
14.5
Intermittent (441–
500 V) [A]
1.9
2.6
3.4
4.3
5.4
7.7
10.1
13.1
17.6
23.2
Continuous kVA
(400 V) [kVA]
0.9
1.3
1.7
2.1
2.8
3.9
5.0
6.9
9.0
11
Continuous kVA
(460 V) [kVA]
0.9
1.3
1.7
2.4
2.7
3.8
5.0
6.5
8.8
11.6
Maximum input current
Continuous (380–
440 V) [A]
1.2
1.6
2.2
2.7
3.7
5.0
6.5
9.0
11.7
14.4
Intermittent (380–
440 V) [A]
1.9
2.6
3.5
4.3
5.9
8.0
10.4
14.4
18.7
23
Continuous (441–
500 V) [A]
1.0
1.4
1.9
2.7
3.1
4.3
5.7
7.4
9.9
13
AQ267037727118en-000101 / 130R030062 | Danfoss A/S © 2021.01
Specifications
VLT® AutomationDrive FC 301/FC 302
Operating Guide
