Danfoss VLT AutomationDrive FC 301 Operating Guide

Enclosure
Power [kW (hp)]
Recommended fuse
size
Recommended maxi-
mum fuse
Recommended circuit
breaker Moeller
Maximum trip lev-
el [A]
2.2 (3.0)
gG-6
gG-25
3.0 (4.0)
gG-10
gG-25
4.0 (5.0)
gG-10
gG-25
5.5 (7.5)
gG-16
gG-25
7.5 (10.0)
gG-16
gG-25
B2/B4
11.0 (15.0)
gG-25
gG-63
–
–
15.0 (20.0)
gG-32
18.5 (25.0)
gG-32
22.0 (30.0)
gG-40
B4/C2
30.0 (40.0)
gG-63
gG-80
–
–
C2/C3
37.0 (50.0)
gG-63
gG-100
–
–
45.0 (60.0)
gG-80
gG-125
C2
55.0 (75.0)
gG-100
gG-160
–
–
75.0 (100.0)
gG-125
8.7.3 UL Compliance
Fuse classification for UL Compliance
N O T I C E
UL COMPLIANCE
To comply with NEC 2017, it is mandatory to use fuses or circuit breakers. Danfoss recommends using a selection of the fuses
listed in the following tables. These fuses are suitable for use on a circuit capable of delivering 100000 A
rms
(symmetrical), 240 V,
480 V, 500 V, or 600 V depending on the drive voltage rating. With the proper fusing, the drive short circuit current rating (SCCR)
is 10000 A
rms
.
For semiconcutor fuse types, the drive controller and the overcurrent protection device must be integrated within the same overall
assembly.
Table 46: UL Fuse Classification Chart
UL class
Fuse overload characteristics
Interrupting rating [A]
AC voltage rating [V]
Available ampere rating
RK1
Ultra fast-acting
200.000
250
600
1–600
T
Fast-acting
200.000
300
600
1–1.200
J
Fast-acting
200.000
600
1–600
CC
Fast acting
200.000
600
5–30
AQ267037727118en-000101 / 130R0300 | 79Danfoss A/S © 2021.01
Specifications
VLT® AutomationDrive FC 301/FC 302
Operating Guide
