Table 47: Recommended Maximum UL Fuse Class, Voltage Range 3x200–240 V, Enclosure Sizes A, B, and C
Class fuses
Semiconductor fuses
Power [kW (hp)]
RK1/J/T [A]
CC [A]
SIBA
Littelfuse
Ferraz-Shawmut (Mersen)
Bussmann (Eaton)
0.25–0.37 (0.34–0.5)
5
5
5017906-005
–
–
FWX-5
0.55–1.1 (0.75–1.5)
10
10
5017906-010
–
–
FWX-10
1.5 (2.0)
15
15
5017906-016
–
–
FWX-15
2.2 (3.0)
20
20
5017906-020
–
–
FWX-20
3.0 (4.0)
25
25
5017906-025
–
–
FWX-25
3.7 (5.0)
30
30
5012406-032
–
–
FWX-30
5.5 (7.5)
50
–
5014006-050
–
–
FWX-50
7.5 (10.0)
60
–
5014006-063
–
–
FWX-60
11.0 (15.0)
80
–
5014006-080
–
–
FWX-80
15–18.5 (20.0–25.0)
125
–
2028220-125
–
–
FWX-125
22.0 (30.0)
150
–
2028220-150
L25S-150
A25X-150
FWX-150
30.0 (40.0)
200
–
2028220-200
L25S-200
A25X-200
FWX-200
37.0 (50.0)
250
–
2028220-250
L25S-250
A25X-250
FWX-250
Table 48: Recommended Maximum UL Fuse Class, Voltage Range 380–500 V, Enclosure Sizes A, B, and C
Class fuses
Semiconductor fuses
Power [kW (hp)]
RK1/J/T [A]
CC [A]
SIBA
Littelfuse
Ferraz-Shawmut (Mersen)
Bussmann (Eaton)
0.37–1.1 (0.5–1.5)
6
6
5017906-006
–
–
FWH-6
1.5–2.2 (2.0–3.0)
10
10
5017906-010
–
–
FWH-10
3.0 (4.0)
15
15
5017906-016
–
–
FWH-15
4.0 (5.0)
20
20
5017906-020
–
–
FWH-20
5.5 (7.5)
25
25
5017906-025
–
–
FWH-25
7.5 (10.0)
30
30
5012406-032
–
–
FWH-30
11.0 (15.0)
40
–
5014006-040
–
–
FWH-40
15.0 (20.0)
50
–
5014006-050
–
–
FWH-50
18.5 (25.0)
60
–
5014006-063
–
–
FWH-60
22.0 (30.0)
80
–
2028220-100
–
–
FWH-80
30.0 (40.0)
100
–
2028220-125
–
–
FWH-100
37.0 (50.0)
125
–
2028220-125
–
–
FWH-125
45.0 (60.0)
150
–
2028220-160
–
–
FWH-150
55.0 (75.0)
200
–
2028220-200
L50-S-225
A50-P-225
FWH-200
75.0 (100.0)
250
–
2028220-250
L50-S-250
A50-P-250
FWH-250
AQ267037727118en-000101 / 130R030080 | Danfoss A/S © 2021.01
