Danfoss VLT AutomationDrive FC 301 Operating Guide

Type designation
P37K
P45K
P55K
P75K
Continuous kVA (575 V) [kVA]
51.8
61.7
61.7
82.7
82.7
99.6
99.6
130.5
Maximum input current
Continuous at 550 V [A]
49
59
59
78.9
78.9
95.3
95.3
124.3
Intermittent at 550 V [A]
74
65
89
87
118
105
143
137
Continuous at 575 V [A]
47
56
56
75
75
91
91
119
Intermittent at 575 V [A]
70
62
85
83
113
100
137
131
Additional specifications
Estimated power loss at rated maximum load [W]
(2)
740
900
900
1100
1100
1500
1500
1800
Efficiency
(3)
0.98
0.98
0.98
0.98
1
High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and
typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to Danfoss
MyDrive® ecoSmart website.
3
Efficiency measured at nominal current. For energy efficiency class, see 8.4 Ambient Conditions. For part load losses, see Danfoss MyDrive® ecoS-
mart website.
8.1.4 Mains Supply 525–690 V (FC 302 only)
Table 38: A3 Enclosure, Mains Supply 525–690 V IP20/Protected Chassis, P1K1–P7K5
Type designation
P1K1
P1K5
P2K2
P3K0
P4K0
P5K5
P7K5
High/normal overload
(1)
HO/NO
HO/NO
HO/NO
HO/NO
HO/NO
HO/NO
HO/NO
Typical shaft output [kW/(hp)]
1.1 (1.5)
1.5 (2.0)
2.2 (3.0)
3.0 (4.0)
4.0 (5.0)
5.5 (7.5)
7.5 (10)
Enclosure protection rating IP20
A3
A3
A3
A3
A3
A3
A3
Output current
Continuous (525–550 V) [A]
2.1
2.7
3.9
4.9
6.1
9.0
11
Intermittent (525–550 V) [A]
3.4
4.3
6.2
7.8
9.8
14.4
17.6
Continuous (551–690 V) [A]
1.6
2.2
3.2
4.5
5.5
7.5
10
Intermittent (551–690 V) [A]
2.6
3.5
5.1
7.2
8.8
12
16
Continuous kVA 525 V
1.9
2.5
3.5
4.5
5.5
8.2
10
Continuous kVA 690 V
1.9
2.6
3.8
5.4
6.6
9.0
12
Maximum input current
Continuous (525–550 V) [A]
1.9
2.4
3.5
4.4
5.5
8.1
9.9
Intermittent (525–550 V) [A]
3.0
3.9
5.6
7.0
8.8
12.9
15.8
Continuous (551–690 V) [A]
1.4
2.0
2.9
4.0
4.9
6.7
9.0
Intermittent (551–690 V) [A]
2.3
3.2
4.6
6.5
7.9
10.8
14.4
Additional specifications
AQ267037727118en-000101 / 130R0300 | 67Danfoss A/S © 2021.01
Specifications
VLT® AutomationDrive FC 301/FC 302
Operating Guide
