Danfoss VLT AutomationDrive FC 301 Operating Guide

Type designation
P11K
P15K
P18K
P22K
P30K
Enclosure protection rating
IP21, IP55, IP66
B1
B1
B2
B2
C1
Output current
Continuous (525–550 V) [A]
19
23
23
28
28
36
36
43
43
54
Intermittent (525–550 V) [A]
30
25
37
31
45
40
58
47
65
59
Continuous (551–600 V) [A]
18
22
22
27
27
34
34
41
41
52
Intermittent (551–600 V) [A]
29
24
35
30
43
37
54
45
62
57
Continuous kVA (550 V) [kVA]
18.1
21.9
21.9
26.7
26.7
34.3
34.3
41
41
51.4
Continuous kVA (575 V) [kVA]
17.9
21.9
21.9
26.9
26.9
33.9
33.9
40.8
40.8
51.8
Maximum input current
Continuous at 550 V [A]
17.2
20.9
20.9
25.4
25.4
32.7
32.7
39
39
49
Intermittent at 550 V [A]
28
23
33
28
41
36
52
43
59
54
Continuous at 575 V [A]
16
20
20
24
24
31
31
37
37
47
Intermittent at 575 V [A]
26
22
32
27
39
34
50
41
56
52
Additional specifications
Estimated power loss at rated
maximum load [W]
(2)
220
300
300
370
370
440
440
600
600
740
Efficiency
(3)
0.98
0.98
0.98
0.98
0.98
1
High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and
typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to Danfoss
MyDrive® ecoSmart website.
3
Efficiency measured at nominal current. For energy efficiency class, see 8.4 Ambient Conditions. For part load losses, see Danfoss MyDrive® ecoS-
mart website.
Table 37: Mains Supply 525–600 V P37K–P75K (FC 302 only), P37K–P75K
Type designation
P37K
P45K
P55K
P75K
High/normal load
(1)
HO
NO
HO
NO
HO
NO
HO
NO
Typical shaft output [kW/(hp)]
37 (50)
45 (60)
45 (60)
55 (75)
55 (75)
75 (100)
75 (100)
90 (125)
Enclosure protection rating IP20
C3
C3
C3
C4
C4
Enclosure protection rating IP21, IP55, IP66
C1
C1
C1
C2
C2
Output current
Continuous (525–550 V) [A]
54
65
65
87
87
105
105
137
Intermittent (525–550 V) [A]
81
72
98
96
131
116
158
151
Continuous (551–600 V) [A]
52
62
62
83
83
100
100
131
Intermittent (551–600 V) [A]
78
68
93
91
125
110
150
144
Continuous kVA (550 V) [kVA]
51.4
61.9
61.9
82.9
82.9
100
100
130.5
AQ267037727118en-000101 / 130R030066 | Danfoss A/S © 2021.01
