8.9 Power Ratings, Weight, and Dimensions
Table 52: Power Ratings, Weight, and Dimensions, Enclosure Size A
Enclosure size
A1
A2
A3
A4
A5
Rated pow-
er [kW (hp)]
200–240 V
0.25–1.5
(0.34–2)
0.25–2.2 (0.34–3)
3–3.7 (4–5)
0.25–2.2
(0.34–3)
0.25–3.7
(0.34–5)
380-480/500 V
0.37–1.5
(0.5–2)
0.37–4 (0.5–5)
5.5–7.5 (7.5–10)
0.37–4
(0.5–5)
0.37–7.5
(0.5–10)
525–600 V
–
–
0.75–7.5 (1–10)
–
0.75–7.5
(1–10)
525–690 V
–
–
1.1–7.5 (1.5–10)
–
–
IP
NEMA
–
20
Chassis
20
Chassis
21
Type 1
20
Chassis
21
Type 1
55/66
Type
12/4X
55/66
Type 12/4X
Height [mm (in)]
Height of mounting
plate
A
(1)
200 (7.9)
268 (10.6)
375 (14.8)
268 (10.6)
375 (14.8)
390 (15.4)
420 (16.5)
Height with ground ter-
mination plate for field-
bus cables
A
316 (12.4)
374 (14.7)
–
374 (14.7)
–
–
–
Distance between
mounting holes
a
190 (7.5)
257 (10.1)
350 (13.8)
257 (10.1)
350 (13.8)
401 (15.8)
402 (15.8)
Width [mm (in)]
Width of mounting plate
B
75 (3)
90 (3.5)
90 (3.5)
130 (5.1)
130 (5.1)
200 (7.9)
242 (9.5)
Width of mounting plate
with 1 C option
B
–
130 (5.1)
130 (5.1)
170 (6.7)
170 (6.7)
–
242 (9.5)
Width of mounting plate
with 2 C options
B
–
150 (5.9)
150 (5.9)
190 (7.5)
190 (7.5)
–
242 (9.5)
Distance between
mounting holes
b
60 (2.4)
70 (2.8)
70 (2.8)
110 (4.3)
110 (4.3)
171 (6.7)
215 (8.5)
Depth [mm (in)]
Depth without option
A/B
C
207 (8.1)
205 (8.1)
207 (8.1)
205 (8.1)
207 (8.1)
175 (6.9)
200 (7.9)
With option A/B
C
222 (8.7)
220 (8.7)
222 (8.7)
220 (8.7)
222 (8.7)
175 (6.9)
200 (7.9)
Screw holes [mm (in)]
c
6.0 (0.24)
8.0 (0.31)
8.0 (0.31)
8.0 (0.31)
8.0 (0.31)
8.25
(0.32)
8.25 (0.32)
d
ø8 (ø0.31)
ø11
(ø0.43)
ø11
(ø0.43)
ø11
(ø0.43)
ø11
(ø0.43)
ø12
(ø0.47)
ø12 (ø0.47)
e
ø5 (ø0.2)
ø5.5
(ø0.22)
ø5.5
(ø0.22)
ø5.5
(ø0.22)
ø5.5
(ø0.22)
ø6.5
(ø0.26)
ø6.5 (ø0.26)
f
5 (0.2)
9 (0.35)
9 (0.35)
6.5 (0.26)
6.5 (0.26)
6 (0.24)
9 (0.35)
