Danfoss VLT AutomationDrive FC 301 Instruction Manual

Type designation P11K P15K P18K P22K
High/Normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output at 550 V (hp [kW]) 10 [7.5] 15 [11] 15 [11] 20 [15] 20 [15] 25 [18.5] 25 [18.5] 30 [22]
Typical Shaft output at 690 V (hp [kW]) 15 [11] 20 [15] 20 [15] 25 [18.5] 25 [18.5] 30 [22] 30 [22] 40 [30]
Enclosure protection rating IP20 B4 B4 B4 B4
Enclosure protection rating IP21, IP55 B2 B2 B2 B2
Output current
Continuous (525–550 V) [A] 14.0 19.0 19.0 23.0 23.0 28.0 28.0 36.0
Intermittent (60 s overload) (525–550 V) [A] 22.4 20.9 30.4 25.3 36.8 30.8 44.8 39.6
Continuous (551–690 V) [A] 13.0 18.0 18.0 22.0 22.0 27.0 27.0 34.0
Intermittent (60 s overload) (551–690 V) [A] 20.8 19.8 28.8 24.2 35.2 29.7 43.2 37.4
Continuous KVA (at 550 V) [KVA] 13.3 18.1 18.1 21.9 21.9 26.7 26.7 34.3
Continuous KVA (at 690 V) [KVA] 15.5 21.5 21.5 26.3 26.3 32.3 32.3 40.6
Maximum input current
Continuous (at 550 V) (A) 15.0 19.5 19.5 24.0 24.0 29.0 29.0 36.0
Intermittent (60 s overload) (at 550 V) (A) 23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Continuous (at 690 V) (A) 14.5 19.5 19.5 24.0 24.0 29.0 29.0 36.0
Intermittent (60 s overload) (at 690 V) (A) 23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Additional specifications
Maximum cable cross-section
2)
for line power/
motor, load share and brake [mm
2
] ([AWG])
35, 25, 25 (2, 4, 4)
Maximum cable cross-section
2)
for line power
disconnect [mm
2
] ([AWG])
16, 10, 10 (6, 8, 8)
Estimated power loss at rated maximum load
(hp [W])
3)
0.201
[150]
0.295
[220]
0.295
[220]
0.402
[300]
0.402
[300]
0.496
[370]
0.496
[370]
0.590
[440]
Efficiency
4)
0.98 0.98 0.98 0.98
Table 8.11 B2/B4 Enclosure, Line Power Supply 525–690 V IP20/IP21/IP55 - Chassis/NEMA 1/NEMA 12 (FC 302 only), P11K-P22K
Specifications Instruction Manual
62 Danfoss A/S © Rev. 09/2014 All rights reserved. MG33AP22
88
