Type designation P30K P37K P45K P55K P75K
High/Normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output at 550 V (hp [kW]) 30 [22] 40 [30] 40 [30] 50 [37] 50 [37] 60 [45] 60 [45] 75 [55] 65 [50] 100 [75]
Typical Shaft output at 690 V (hp [kW]) 40 [30] 50 [37] 50 [37] 60 [45] 60 [45] 75 [55] 75 [55] 100 [75] 100 [75] 125 [90]
Enclosure protection rating IP20 B4 C3 C3 D3h D3h
Enclosure protection rating IP21, IP55 C2 C2 C2 C2 C2
Output current
Continuous (525–550 V) [A] 36.0 43.0 43.0 54.0 54.0 65.0 65.0 87.0 87.0 105
Intermittent (60 s overload) (525–550 V)
[A] 54.0 47.3 64.5 59.4 81.0 71.5 97.5 95.7 130.5 115.5
Continuous (551–690 V) [A] 34.0 41.0 41.0 52.0 52.0 62.0 62.0 83.0 83.0 100
Intermittent (60 s overload) (551–690 V)
[A] 51.0 45.1 61.5 57.2 78.0 68.2 93.0 91.3 124.5 110
continuous KVA (at 550 V) [KVA] 34.3 41.0 41.0 51.4 51.4 61.9 61.9 82.9 82.9 100
continuous KVA (at 690 V) [KVA] 40.6 49.0 49.0 62.1 62.1 74.1 74.1 99.2 99.2 119.5
Maximum input current
Continuous (at 550 V) [A] 36.0 49.0 49.0 59.0 59.0 71.0 71.0 87.0 87.0 99.0
Intermittent (60 s overload) (at 550 V) [A] 54.0 53.9 72.0 64.9 87.0 78.1 105.0 95.7 129 108.9
Continuous (at 690 V) [A] 36.0 48.0 48.0 58.0 58.0 70.0 70.0 86.0 - -
Intermittent (60 s overload) (at 690 V) [A] 54.0 52.8 72.0 63.8 87.0 77.0 105 94.6 - -
Additional specifications
Maximum cable cross-section for line
power and motor [mm
2
] ([AWG])
150 (300 MCM)
Maximum cable cross-section for load
share and brake [mm
2
] ([AWG])
95 (3/0)
Maximum cable cross-section
2)
for line
power disconnect [mm
2
] ([AWG])
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM,
300 MCM, 4/0)
-
Estimated power loss
at rated maximum load (hp [W])
3)
0.805
[600]
0.992
[740]
0.992
[740]
1.207
[900]
1.207
[900]
1.475
[1100]
1.475
[1100]
2.012
[1500]
2.012
[1500]
2.414
[1800]
Efficiency
4)
0.98 0.98 0.98 0.98 0.98
Table 8.12 B4, C2, C3 Enclosure, Line Power Supply 525–690 V IP20/IP21/IP55 - Chassis/NEMA1/NEMA 12 (FC 302 only), P30K-P75K
For fuse ratings, see chapter 8.7 Fuses and Circuit Breakers.
1) High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2) The three values for the maximum cable cross-section are for single core, flexible wire and flexible wire with sleeve, respectively.
3) Applies for dimensioning of adjustable frequency drive cooling. If the switching frequency is higher than the default setting, the power losses
may increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to
www.danfoss.com/vltenergyefficiency
4) Efficiency measured at nominal current. For energy efficiency class, see chapter 8.4 Ambient Conditions. For part load losses, see
www.danfoss.com/vltenergyefficiency.
Specifications Instruction Manual
MG33AP22 Danfoss A/S © Rev. 09/2014 All rights reserved. 63
8 8
