8.7.1 CE Compliance
200–240 V
Enclosure Power (hp [kW]) Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker Moeller
Maximum trip level
[A]
A1 0.34–2 [0.25–1.5] gG-10 gG-25 PKZM0-16 16
A2 0.34–3 [0.25–2.2] gG-10 (0.25–1.5)
gG-16 (2.2)
gG-25 PKZM0-25 25
A3 4–5 [3.0–3.7] gG-16 (4 [3])
gG-20 (5 [3.7])
gG-32 PKZM0-25 25
A4 0.34–3 [0.25–2.2] gG-10 (0.25–1.5)
gG-16 (2.2)
gG-32 PKZM0-25 25
A5 0.34–5 [0.25–3.7] gG-10 (0.34–2 [0.25–1.5])
gG-16 (3–4 [2.2–3])
gG-20 (5 [3.7])
gG-32 PKZM0-25 25
B1 7.5–10 [5.5–7.5] gG-25 (5.5)
gG-32 (7.5)
gG-80 PKZM4-63 63
B2 15 [11] gG-50 gG-100 NZMB1-A100 100
B3 7.5 [5.5] gG-25 gG-63 PKZM4-50 50
B4 10–20 [7.5-15] gG-32 (7.5)
gG-50 (11)
gG-63 (15)
gG-125 NZMB1-A100 100
C1 20–30 [15–22] gG-63 (15)
gG-80 (18.5)
gG-100 (22)
gG-160 (15–18.5)
aR-160 (22)
NZMB2-A200 160
C2 40–50 [30–37] aR-160 (30)
aR-200 (37)
aR-200 (30)
aR-250 (37)
NZMB2-A250 250
C3 25–30 [18.5–22] gG-80 (18.5)
aR-125 (22)
gG-150 (18.5)
aR-160 (22)
NZMB2-A200 150
C4 40–50 [30–37] aR-160 (30)
aR-200 (37)
aR-200 (30)
aR-250 (37)
NZMB2-A250 250
Table 8.13 200–240 V, Enclosure Types A, B and C
