Danfoss VLT AutomationDrive FC 301 Instruction Manual

380–500 V
Enclosure Power (hp [kW]) Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker Moeller
Maximum trip level
[A]
A1 0.5–2 [0.37–1.5] gG-10 gG-25 PKZM0-16 16
A2 0.5–5 [0.37–4.0] gG-10 (0.37–3)
gG-16 (4)
gG-25 PKZM0-25 25
A3 7.5–10 [5.5–7.5] gG-16 gG-32 PKZM0-25 25
A4 0.5–5 [0.37–4] gG-10 (0.37–3)
gG-16 (4)
gG-32 PKZM0-25 25
A5 0.5–10 [0.37–7.5] gG-10 (0.37–3)
gG-16 (4–7.5)
gG-32 PKZM0-25 25
B1 15–20 [11–15] gG-40 gG-80 PKZM4-63 63
B2 25–30 [18.5–22] gG-50 (18.5)
gG-63 (22)
gG-100 NZMB1-A100 100
B3 15–20 [11–15] gG-40 gG-63 PKZM4-50 50
B4 25–40 [18.5–30] gG-50 (18.5)
gG-63 (22)
gG-80 (30)
gG-125 NZMB1-A100 100
C1 40–60 [30–45] gG-80 (30)
gG-100 (37)
gG-160 (45)
gG-160 NZMB2-A200 160
C2 75–100 [55–75] aR-200 (55)
aR-250 (75)
aR-250 NZMB2-A250 250
C3 50–60 [37-45] gG-100 (37)
gG-160 (45)
gG-150 (37)
gG-160 (45)
NZMB2-A200 150
C4 75–100 [55–75] aR-200 (55)
aR-250 (75)
aR-250 NZMB2-A250 250
Table 8.14 380–500 V, Enclosure Types A, B and C
