Danfoss VLT AutomationDrive FC 301 Instruction Manual

525–600 V
Enclosure Power (hp [kW]) Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker
Moeller
Maximum trip level
[A]
A2 1–5 [0.75–4.0] gG-10 gG-25 PKZM0-25 25
A3 7.5–10 [5.5–7.5] gG-10 (7.5 [5.5])
gG-16 (10 [7.5])
gG-32 PKZM0-25 25
A5 1–10 [0.75–7.5] gG-10 (0.75–5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B1 15–24 [11–18] gG-25 (15 [11])
gG-32 (20 [15])
gG-40 (25 [18.5])
gG-80 PKZM4-63 63
B2 30–40 [22–30] gG-50 (30 [22])
gG-63 (40 [30])
gG-100 NZMB1-A100 100
B3 15–20 [11–15] gG-25 (11)
gG-32 (15)
gG-63 PKZM4-50 50
B4 25–40 [18.5–30] gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-125 NZMB1-A100 100
C1 50–75 [37–55] gG-63 (50 [37])
gG-100 (60 [45])
aR-160 (75 [55])
gG-160 (50–60 [37–45])
aR-250 (75 [55])
NZMB2-A200 160
C2 100 [75] aR-200 (75) aR-250 NZMB2-A250 250
C3 50–60 [37-45] gG-63 (37)
gG-100 (45)
gG-150 NZMB2-A200 150
C4 75–100 [55–75] aR-160 (55)
aR-200 (75)
aR-250 NZMB2-A250 250
Table 8.15 525–600 V, Enclosure Types A, B and C
525–690 V
Enclosure Power (hp [kW]) Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker
Moeller
Maximum trip level
[A]
A3 1.5 [1.1]
2 [1.5]
3 [2.2]
4 [3]
5 [4]
7.5 [5.5]
10 [7.5]
gG-6
gG-6
gG-6
gG-10
gG-10
gG-16
gG-16
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
PKZM0-16 16
B2/B4 15 [11]
20 [15]
24 [18]
30 [22]
gG-25 (11)
gG-32 (15)
gG-32 (18)
gG-40 (22)
gG-63
- -
B4/C2 40 [30] gG-63 (30) gG-80 (30) - -
C2/C3 50 [37]
60 [45]
gG-63 (37)
gG-80 (45)
gG-100 (37)
gG-125 (45)
- -
C2 75 [55]
100 [75]
gG-100 (55)
gG-125 (75)
gG-160 (55–75)
- -
Table 8.16 525–690 V, Enclosure Types A, B and C
Specifications
Instruction Manual
72 Danfoss A/S © Rev. 09/2014 All rights reserved. MG33AP22
