8.7.2 UL Compliance
200–240 V
Recommended maximum fuse
Power
(hp [kW])
Bussmann
Type RK1
1)
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
0.34–0.5
[0.25–0.37]
KTN-R-05 JKS-05 JJN-05 FNQ-R-5 KTK-R-5 LP-CC-5
0.75–1.5
[0.55–1.1]
KTN-R-10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
2 [1.5] KTN-R-15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
3 [2.2] KTN-R-20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
4 [3.0] KTN-R-25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
5 [3.7] KTN-R-30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
7.5 [5.5] KTN-R-50 KS-50 JJN-50 - - -
10 [7.5] KTN-R-60 JKS-60 JJN-60 - - -
15 [11] KTN-R-80 JKS-80 JJN-80 - - -
20–25 [15–18.5] KTN-R-125 JKS-125 JJN-125 - - -
30 [22] KTN-R-150 JKS-150 JJN-150 - - -
40 [30] KTN-R-200 JKS-200 JJN-200 - - -
50 [37] KTN-R-250 JKS-250 JJN-250 - - -
Table 8.17 200–240 V, Enclosure Types A, B and C
Recommended maximum fuse
Power
(hp [kW])
SIBA
Type RK1
Littelfuse
Type RK1
Ferraz-
Shawmut
Type CC
Ferraz-
Shawmut
Type RK1
3)
Bussmann
Type JFHR2
2)
Littelfuse
JFHR2
Ferraz-
Shawmut
JFHR2
4)
Ferraz-
Shawmut
J
0.34–0.5
[0.25–0.37]
5017906-005 KLN-R-05 ATM-R-05 A2K-05-R FWX-5 - - HSJ-6
0.75–1.5
[0.55–1.1]
5017906-010 KLN-R-10 ATM-R-10 A2K-10-R FWX-10 - - HSJ-10
2 [1.5] 5017906-016 KLN-R-15 ATM-R-15 A2K-15-R FWX-15 - - HSJ-15
3 [2.2] 5017906-020 KLN-R-20 ATM-R-20 A2K-20-R FWX-20 - - HSJ-20
4 [3.0] 5017906-025 KLN-R-25 ATM-R-25 A2K-25-R FWX-25 - - HSJ-25
5 [3.7] 5012406-032 KLN-R-30 ATM-R-30 A2K-30-R FWX-30 - - HSJ-30
7.5 [5.5] 5014006-050 KLN-R-50 - A2K-50-R FWX-50 - - HSJ-50
10 [7.5] 5014006-063 KLN-R-60 - A2K-60-R FWX-60 - - HSJ-60
15 [11] 5014006-080 KLN-R-80 - A2K-80-R FWX-80 - - HSJ-80
20–25 [15–18.5] 2028220-125 KLN-R-125 - A2K-125-R FWX-125 - - HSJ-125
30 [22] 2028220-150 KLN-R-150 - A2K-150-R FWX-150 L25S-150 A25X-150 HSJ-150
40 [30] 2028220-200 KLN-R-200 - A2K-200-R FWX-200 L25S-200 A25X-200 HSJ-200
50 [37] 2028220-250 KLN-R-250 - A2K-250-R FWX-250 L25S-250 A25X-250 HSJ-250
Table 8.18 200–240 V, Enclosure Types A, B and C
1) KTS fuses from Bussmann may substitute KTN for 240 V adjustable frequency drives.
2) FWH fuses from Bussmann may substitute FWX for 240 V adjustable frequency drives.
3) A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V adjustable frequency drives.
4) A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V adjustable frequency drives.
