VLT
®
AutomationDrive EtherNet/IP
- P a r a m e t e r s –
MG.90.Jx.02 ver. 5
th
September 2007 – VLT is a registered Danfoss trademark 35
(8-55) Set-up Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*Logic OR [3]
Function:
Select control of the frequency converter set-
up selection via the terminals (digital input)
and/or via the fieldbus.
N.B. This parameter is active only when
par. 8-01 Control site is set to [0] Digital
and control word.
(8-56) Preset Reference Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*Logic OR [3]
Function:
Select control of the frequency converter
Preset Reference selection via the terminals
(digital input) and/or via the fieldbus.
N.B. This parameter is active only when
par. 8-01 Control site is set to [0] Digital
and control word.
